Performance Data
13AJN Series
11
Performance Data @ AHRI Standard Conditions—Cooling
Model Numbers
80°F [26.5°C] DB/67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
Sound
Rating
dB
Indoor
CFM [L/s]
Outdoor
Unit
13AJN
Indoor
Coil and/or
Air Handler
Total
Capacity
BTU/H [kW]
Net
Sensible
BTU/H [kW]
Net
Latent
BTU/H [kW]
EER SEER
30
(AJN)
RCQD-3621(RGRM-07?MAE?) 28,800 [8.4] 22,850 [6.7] 5,950 [1.7] 11.50 13.50 74 950 [448]
RCQD-3621(RGRM-07?YBG?) 29,200 [8.6] 23,650 [6.9] 5,550 [1.6] 11.50 13.50 74 1,050 [495]
RCQD-3621(RGRM-09?ZAJ?) 29,000 [8.5] 23,000 [6.7] 6,000 [1.8] 11.50 14.00 74 950 [448]
RCQD-3621(RGRM-10?ZAJ?) 29,200 [8.6] 23,400 [6.9] 5,800 [1.7] 11.50 14.00 74 1,025 [484]
RCQD-3621(RGTM-06?MAE?) 28,800 [8.4] 22,600 [6.6] 6,200 [1.8] 12.00 14.50 74 900 [425]
RCQD-3621(RGTM-07?RBG?) 29,600 [8.7] 24,000 [7.0] 5,600 [1.6] 12.00 14.50 74 1,050 [495]
RCQD-3621(RGTM-09?ZAJ?) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 975 [460]
RCQD-3621(RHWB-04WMX36A) 29,800 [8.7] 24,500 [7.2] 5,300 [1.6] 12.00 14.50 74 1,100 [519]
RCQD-3621(RHWB-06WMX48A) 29,400 [8.6] 23,700 [6.9] 5,700 [1.7] 12.00 14.50 74 1,025 [484]
RCQD-3621(ROCA-070E03) 29,200 [8.6] 23,400 [6.9] 5,800 [1.7] 12.00 14.50 74 1,000 [472]
RCQD-3621(ROCA-070E04) 29,200 [8.6] 23,400 [6.9] 5,800 [1.7] 12.00 14.50 74 1,000 [472]
RCQD-3621(ROLA-070E03) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 975 [460]
RCQD-3621(ROLA-070E04) 29,200 [8.6] 23,400 [6.9] 5,800 [1.7] 12.00 14.50 74 1,025 [484]
RCQD-3621(ROLA-115E05) 29,600 [8.7] 24,000 [7.0] 5,600 [1.6] 12.00 14.50 74 1,050 [495]
RCQD-3621+RXMD-C04 28,600 [8.4] 22,900 [6.7] 5,700 [1.7] 11.00 13.00 74 1,025 [484]
RCQD-3624(RGFE-09?ZCM?) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 975 [460]
RCQD-3624(RGFE-10?ZCM?) 29,400 [8.6] 23,600 [6.9] 5,800 [1.7] 12.00 14.50 74 1,000 [472]
RCQD-3624(RGFE-12?RCM?) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 1,025 [484]
RCQD-3624(RGFG-09?ZCM?) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 975 [460]
RCQD-3624(RGFG-10?ZCM?) 29,200 [8.6] 23,400 [6.9] 5,800 [1.7] 12.00 14.50 74 1,000 [472]
RCQD-3624(RGFG-12?RCM?) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 1,025 [484]
RCQD-3624(RGJF-09?ZCM?) 29,200 [8.6] 23,400 [6.9] 5,800 [1.7] 12.00 14.50 74 1,025 [484]
RCQD-3624(RGJF-10?ZCM?) 29,600 [8.7] 24,000 [7.0] 5,600 [1.6] 12.00 14.50 74 1,050 [495]
RCQD-3624(RGJF-12?RCM?) 29,600 [8.7] 23,950 [7.0] 5,650 [1.7] 12.00 14.50 74 1,050 [495]
RCQD-3624(RGPE-07?BRQ?) 29,600 [8.7] 23,950 [7.0] 5,650 [1.7] 12.00 14.50 74 1,050 [495]
RCQD-3624(RGPE-10?BRM?) 29,000 [8.5] 22,750 [6.7] 6,250 [1.8] 12.00 14.50 74 900 [425]
RCQD-3624(RGPE-12?ARM?) 28,800 [8.4] 22,450 [6.6] 6,350 [1.9] 12.00 14.50 74 875 [413]
RCQD-3624(RGPT-07?BRQ?) 29,600 [8.7] 23,950 [7.0] 5,650 [1.7] 12.00 14.50 74 1,050 [495]
RCQD-3624(RGPT-10?BRM?) 29,800 [8.7] 24,250 [7.1] 5,550 [1.6] 12.00 14.50 74 1,075 [507]
RCQD-3624(RGPT-12?ARM?) 29,600 [8.7] 23,750 [7.0] 5,850 [1.7] 12.00 14.50 74 975 [460]
RCQD-3624(RGRM-07?YBG?) 29,200 [8.6] 23,650 [6.9] 5,550 [1.6] 11.50 13.50 74 1,050 [495]
RCQD-3624(RGRM-09?ZAJ?) 29,000 [8.5] 23,000 [6.7] 6,000 [1.8] 12.00 14.50 74 950 [448]
RCQD-3624(RGRM-10?ZAJ?) 28,800 [8.4] 22,500 [6.6] 6,300 [1.8] 12.00 14.50 74 875 [413]
RCQD-3624(RGRM-12?RAJ?) 29,000 [8.5] 22,850 [6.7] 6,150 [1.8] 12.00 14.50 74 925 [437]
RCQD-3624(RGTM-07?RBG?) 29,600 [8.7] 23,950 [7.0] 5,650 [1.7] 12.00 14.50 74 1,050 [495]
RCQD-3624(RGTM-09?ZAJ?) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 975 [460]
RCQD-3624(RGTM-10?RBJ?) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 975 [460]
RCQD-3624(ROCA-070E03) 29,200 [8.6] 23,400 [6.9] 5,800 [1.7] 12.00 14.50 74 1,000 [472]
RCQD-3624(ROCA-070E04) 29,200 [8.6] 23,400 [6.9] 5,800 [1.7] 12.00 14.50 74 1,000 [472]
RCQD-3624(ROLA-070E03) 29,400 [8.6] 23,550 [6.9] 5,850 [1.7] 12.00 14.50 74 975 [460]
RCQD-3624(ROLA-070E04) 29,400 [8.6] 23,600 [6.9] 5,800 [1.7] 12.00 14.50 74 1,025 [484]
RCQD-3624(ROLA-115E05) 29,600 [8.7] 23,950 [7.0] 5,650 [1.7] 12.00 14.50 74 1,050 [495]
RCQD-3624+RXMD-C04 28,600 [8.4] 22,900 [6.7] 5,700 [1.7] 11.00 13.00 74 1,025 [484]
RHKL-HM3617(RCSL-H*3617) 28,000 [8.2] 20,800 [6.1] 7,200 [2.1] 11.50 14.00 74 1,025 [484]
RHLL-HM3617(RCSL-H*3617) 28,000 [8.2] 20,800 [6.1] 7,200 [2.1] 11.50 14.00 74 1,000 [472]
RHSL-HM3017(RCSL-H*3617) 27,600 [8.1] 20,400 [6.0] 7,200 [2.1] 11.00 13.00 74 975 [460]
36
(AJN,
ACN,
ADN)
RCFL-H*3617 ➀
34,200 [10.0] 24,000 [7.0] 10,200 [3.0] 11.00 13.00 74 1,000 [472]
RHAL-FR36P 34,800 [10.2] 26,200 [7.7] 8,500 [2.5] 11.00 13.00 74 1,175 [554]
RHAL-FR36T 34,800 [10.2] 26,200 [7.7] 8,500 [2.5] 10.30 13.00 74 1,175 [554]
RHBL-FR36T 34,800 [10.2] 26,200 [7.7] 8,500 [2.5] 10.75 14.00 74 1,150 [543]
Rev.
5/17/12
➀ Highest sales volume tested combination required by D.O.E. test procedures. [ ] Designates Metric Conversions
