Rheem 13AJN SERIES User Manual

Air
Performance Data
13AJN Series
12
Performance Data @ AHRI Standard Conditions—Cooling
Model Numbers
80°F [26.5°C] DB/67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
Sound
Rating
dB
Indoor
CFM [L/s]
Outdoor
Unit
13AJN
Indoor
Coil and/or
Air Handler
Total
Capacity
BTU/H [kW]
Net
Sensible
BTU/H [kW]
Net
Latent
BTU/H [kW]
EER SEER
36
(AJN,
ACN,
ADN)
RCFL-A*3617 34,200 [10.0] 23,950 [7.0] 10,250 [3.0] 10.50 13.00 74 1,000 [472]
RCFL-A*3617(RGFE-06?MCK?) 34,400 [10.1] 24,200 [7.1] 10,200 [3.0] 11.00 13.00 74 1,000 [472]
RCFL-A*3617(RGFE-07?MCK?) 34,400 [10.1] 24,000 [7.0] 10,400 [3.0] 11.00 13.00 74 1,025 [484]
RCFL-A*3617(RGFG-06?MCK?) 34,400 [10.1] 24,200 [7.1] 10,200 [3.0] 11.00 13.00 74 1,000 [472]
RCFL-A*3617(RGFG-07?MCK?) 34,400 [10.1] 24,000 [7.0] 10,400 [3.0] 11.00 13.00 74 1,000 [472]
RCFL-A*3617(RGGE-06?MCK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3617(RGGE-07?MCK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.00 74 1,025 [484]
RCFL-A*3617(RGJF-06?MCK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3617(RGLE-07?AMK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3617(RGLT-07?AMK?) 34,800 [10.2] 24,800 [7.3] 10,000 [2.9] 11.50 13.50 74 1,050 [495]
RCFL-A*3617(RGPE-07?AMK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,000 [472]
RCFL-A*3617(RGPT-05?BMK?) 34,800 [10.2] 24,600 [7.2] 10,200 [3.0] 11.00 13.00 74 1,050 [495]
RCFL-A*3617(RGPT-07?AMK?) 34,800 [10.2] 24,800 [7.3] 10,000 [2.9] 11.50 13.50 74 1,050 [495]
RCFL-A*3617(RGRM-04?MAE?) 34,400 [10.1] 24,000 [7.0] 10,400 [3.0] 11.00 13.00 74 1,025 [484]
RCFL-A*3617(RGRM-06?MAE?) 34,400 [10.1] 24,200 [7.1] 10,200 [3.0] 11.00 13.00 74 1,000 [472]
RCFL-A*3617(RGTM-06?MAE?) 34,800 [10.2] 24,800 [7.3] 10,000 [2.9] 11.00 13.00 74 1,075 [507]
RCFL-A*3617(RHWB-04WMX36A) 35,200 [10.3] 25,600 [7.5] 9,600 [2.8] 11.00 13.00 74 1,150 [543]
RCFL-A*3617(RHWB-06WMX48A) 35,200 [10.3] 25,600 [7.5] 9,600 [2.8] 11.00 13.00 74 1,150 [543]
RCFL-A*3617(ROCA-070E03) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,000 [472]
RCFL-A*3617(ROCA-070E04) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,000 [472]
RCFL-A*3617(ROLA-070E04) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621 34,200 [10.0] 23,950 [7.0] 10,250 [3.0] 10.50 13.00 74 1,000 [472]
RCFL-A*3621(RGFE-06?MCK?) 34,400 [10.1] 24,200 [7.1] 10,200 [3.0] 11.50 13.00 74 1,000 [472]
RCFL-A*3621(RGFE-07?MCK?) 34,400 [10.1] 24,200 [7.1] 10,200 [3.0] 11.00 13.00 74 1,025 [484]
RCFL-A*3621(RGFE-09?ZCM?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621(RGFE-10?ZCM?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621(RGFG-06?MCK?) 34,400 [10.1] 24,200 [7.1] 10,200 [3.0] 11.00 13.00 74 1,000 [472]
RCFL-A*3621(RGFG-07?MCK?) 34,400 [10.1] 24,200 [7.1] 10,200 [3.0] 11.00 13.00 74 1,000 [472]
RCFL-A*3621(RGFG-09?ZCM?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621(RGFG-10?ZCM?) 34,800 [10.2] 24,800 [7.3] 10,000 [2.9] 11.50 13.50 74 1,050 [495]
RCFL-A*3621(RGGE-06?MCK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621(RGGE-07?MCK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621(RGGE-09?ZCM?) 34,800 [10.2] 24,400 [7.1] 10,400 [3.0] 11.50 13.50 74 1,000 [472]
RCFL-A*3621(RGGE-10?ZCM?) 35,000 [10.3] 24,800 [7.3] 10,200 [3.0] 11.50 13.50 74 1,050 [495]
RCFL-A*3621(RGJF-06?MCK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621(RGLE-07?AMK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621(RGLE-07?BRQ?) 34,800 [10.2] 24,400 [7.1] 10,400 [3.0] 11.50 13.50 74 1,025 [484]
RCFL-A*3621(RGLE-10?BRM?) 35,200 [10.3] 24,800 [7.3] 10,400 [3.0] 11.50 14.00 74 1,050 [495]
RCFL-A*3621(RGLT-07?AMK?) 35,000 [10.3] 25,000 [7.3] 10,000 [2.9] 11.50 13.50 74 1,075 [507]
RCFL-A*3621(RGLT-07?BRQ?) 34,800 [10.2] 24,600 [7.2] 10,200 [3.0] 11.50 14.00 74 975 [460]
RCFL-A*3621(RGLT-10?BRM?) 34,800 [10.2] 24,600 [7.2] 10,200 [3.0] 11.50 14.00 74 975 [460]
RCFL-A*3621(RGPE-07?AMK?) 34,600 [10.1] 24,200 [7.1] 10,400 [3.0] 11.50 13.50 74 1,000 [472]
RCFL-A*3621(RGPE-07?BRQ?) 35,000 [10.3] 24,800 [7.3] 10,200 [3.0] 11.50 13.50 74 1,050 [495]
RCFL-A*3621(RGPE-10?BRM?) 35,200 [10.3] 25,000 [7.3] 10,200 [3.0] 11.50 14.00 74 1,075 [507]
RCFL-A*3621(RGPT-05?BMK?) 34,800 [10.2] 24,900 [7.3] 9,900 [2.9] 11.00 13.00 74 1,075 [507]
RCFL-A*3621(RGPT-07?AMK?) 34,800 [10.2] 24,800 [7.3] 10,000 [2.9] 11.50 13.50 74 1,050 [495]
RCFL-A*3621(RGPT-07?BRQ?) 34,800 [10.2] 24,600 [7.2] 10,200 [3.0] 11.50 14.00 74 975 [460]
RCFL-A*3621(RGPT-10?BRM?) 34,800 [10.2] 24,600 [7.2] 10,200 [3.0] 11.50 14.00 74 975 [460]
RCFL-A*3621(RGRM-04?MAE?) 34,400 [10.1] 24,000 [7.0] 10,400 [3.0] 11.00 13.00 74 1,025 [484]
RCFL-A*3621(RGRM-06?MAE?) 34,400 [10.1] 24,200 [7.1] 10,200 [3.0] 11.00 13.00 74 1,000 [472]
Rev.
5/17/12
➀ Highest sales volume tested combination required by D.O.E. test procedures. [ ] Designates Metric Conversions
