Rheem RA13 Series User Manual

Air
Performance Data
RA13 Series
Performance Data @ AHRI Standard Conditions – Cooling
High Sales Volume Tested Combination (HSVTC)
Outdoor
Unit
Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1318AJ1 RCF2417STAM 17600 [5.2] 13100 [3.8] 4500 [1.3] 13 11 600 [283.2] 7507439
RA1324AJ1 RCF2417STAM 23600 [6.9] 17600 [5.2] 6000 [1.8] 13 11 800 [377.6] 7507649
RA1330AJ1 RCF3617STAM 28400 [8.3] 21600 [6.3] 6800 [2.0] 13 11 1000 [471.9] 7507846
RA1336AC1 RCF3617STAM 34600 [10.1] 24500 [7.2] 10100 [3.0] 13 11 1025 [483.7] 7508191
RA1336AJ1 RCF3617STAM 34600 [10.1] 24500 [7.2] 10100 [3.0] 13 11 1025 [483.7] 7508557
RA1342AC1 RCF4821STAM 40500 [11.9] 30300 [8.9] 10200 [3.0] 13 11 1400 [660.7] 7511558
RA1342AJ1 RCF4821STAM 40500 [11.9] 30300 [8.9] 10200 [3.0] 13 11 1400 [660.7] 7511792
RA1348AC1 RCF4821STAM 47500 [13.9] 34100 [10.0] 13400 [3.9] 13 11 1500 [707.9] 7508923
RA1348AJ1 RCF4821STAM 47500 [13.9] 34100 [10.0] 13400 [3.9] 13 11 1500 [707.9] 7509148
RA1360AC1 RCF6024STAM 56000 [16.4] 39600 [11.6] 16400 [4.8] 13 11 1600 [755.1] 7509314
RA1360AJ1 RCF6024STAM 56000 [16.4] 39600 [11.6] 16400 [4.8] 13 11 1600 [755.1] 7509436
Coil Only Ratings
Outdoor
Unit
Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1318AJ1
RCF2414STAM+RXMD-C04 17600 [5.2] 12600 [3.7] 5000 [1.5] 13 11 600 [283.2] 7507408
RCF2417HTAM+RXMD-C04 17500 [5.1] 12300 [3.6] 5200 [1.5] 13 11 600 [283.2] 7507423
RCF2417MTAM+RXMD-C04 17500 [5.1] 12300 [3.6] 5200 [1.5] 13 11 600 [283.2] 7507438
RCF2421MTAM+RXMD-C04 17500 [5.1] 12300 [3.6] 5200 [1.5] 13 11 600 [283.2] 7507491
RA1324AJ1
RCF2414STAM+RXMD-C04 23800 [7.0] 17100 [5.0] 6700 [2.0] 13 11 800 [377.6] 7507612
RCF2417HTAM+RXMD-C04 23400 [6.9] 16500 [4.8] 6900 [2.0] 13 11 800 [377.6] 7507630
RCF2417MTAM+RXMD-C04 23400 [6.9] 16500 [4.8] 6900 [2.0] 13 11 800 [377.6] 7507648
RCF2421MTAM+RXMD-C04 23400 [6.9] 16500 [4.8] 6900 [2.0] 13 11 800 [377.6] 7507716
RA1330AJ1
RCF3621MTAM+RXMD-C04 29800 [8.7] 21900 [6.4] 7900 [2.3] 13.5 11.5 1000 [471.9] 7507895
RCF3621STAM+RXMD-C04 28400 [8.3] 20500 [6.0] 7900 [2.3] 13 11 1000 [471.9] 7507926
RCF3624HTAM+RXMD-C04 30400 [8.9] 22200 [6.5] 8200 [2.4] 13.5 11.5 1000 [471.9] 7507950
RCF3624MTAM+RXMD-C04 29800 [8.7] 21900 [6.4] 7900 [2.3] 13.5 11.5 1000 [471.9] 7507973
RA1336AC1
RCF3621MTAM+RXMD-C04 36600 [10.7] 24900 [7.3] 11700 [3.4] 13.5 11.5 1025 [483.7] 7508240
RCF3621STAM+RXMD-C04 34400 [10.1] 23100 [6.8] 11300 [3.3] 13 11 1025 [483.7] 7508271
RCF3624HTAM+RXMD-C04 37400 [11.0] 25600 [7.5] 11800 [3.5] 13.5 11.5 1025 [483.7] 7508298
RCF3624MTAM+RXMD-C04 36600 [10.7] 24900 [7.3] 11700 [3.4] 13.5 11.5 1025 [483.7] 7508325
RA1336AJ1
RCF3621MTAM+RXMD-C04 36600 [10.7] 24900 [7.3] 11700 [3.4] 13.5 11.5 1025 [483.7] 7508606
RCF3621STAM+RXMD-C04 34400 [10.1] 23100 [6.8] 11300 [3.3] 13 11 1025 [483.7] 7508637
RCF3624HTAM+RXMD-C04 37400 [11.0] 25600 [7.5] 11800 [3.5] 13.5 11.5 1025 [483.7] 7508664
RCF3624MTAM+RXMD-C04 36600 [10.7] 24900 [7.3] 11700 [3.4] 13.5 11.5 1025 [483.7] 7508691
RA1342AC1
RCF4824HTAM+RXMD-C04 41500 [12.2] 29400 [8.6] 12100 [3.5] 13 11.5 1400 [660.7] 7511616
RCF4824STAM+RXMD-C04 40000 [11.7] 28000 [8.2] 12000 [3.5] 13 11 1375 [648.9] 7511643
RA1342AJ1
RCF4824HTAM+RXMD-C04 41500 [12.2] 29400 [8.6] 12100 [3.5] 13 11.5 1400 [660.7] 7511850
RCF4824STAM+RXMD-C04 40000 [11.7] 28000 [8.2] 12000 [3.5] 13 11 1375 [648.9] 7511877
RA1348AC1
RCF4824HTAM+RXMD-C04 49500 [14.5] 34200 [10.0] 15300 [4.5] 13 11.5 1500 [707.9] 7508968
RCF4824STAM+RXMD-C04 47500 [13.9] 34100 [10.0] 13400 [3.9] 13 11 1500 [707.9] 7509019
RA1348AJ1
RCF4824HTAM+RXMD-C04 49500 [14.5] 34200 [10.0] 15300 [4.5] 13 11.5 1500 [707.9] 7509188
RCF4824STAM+RXMD-C04 47500 [13.9] 34100 [10.0] 13400 [3.9] 13 11 1500 [707.9] 7509210
RA1360AC1
RCF6024HTAM+RXMD-C04 56000 [16.4] 39600 [11.6] 16400 [4.8] 13 11 1600 [755.1] 7509313
RCF6024HTAM+RXMD-C04 56000 [16.4] 39600 [11.6] 16400 [4.8] 13 11 1600 [755.1] 7509435
[ ] Designates Metric Conversions
