Rheem RA13 Series User Manual

R
96 V A
70
2 3 17 M S A
Brand Series Motor Major Rev Input
BTU/HR
Stages Air Flow Cabinet
Width
Configuration Nox Minor Rev
Rheem
90 - 90 AFUE 92 - 92 AFUE 95 - 95 AFUE 96 - 96 AFUE 97 - 97 AFUE
V - Variable speed T - Constant
Torque (X-13)
P - PSC
A - 1st Design
040 - 42,000 [12.31 kW] 060 - 56,000 [16.41 kW] 070 - 70,000 [20.51 kW] 085 - 84,000 [24.62 kW] 100 - 98,000 [28.72 kW] 115 - 112,000 [32.82 kW]
1 - Single-stage 2 - Two-stage M - Modulating
3 - up to 3 ton 5 - 3 1/2 up to 5 ton
14 - 14" 17 - 17.5" 21 - 21" 24 - 24.5"
M - Multi X - Low Nox
S - Standard
A - 1st Design
Air
Model Number Identification
RA13 Series
7
R
80 2 V A
075
3 17 M S A
Brand Series Stages Motor Major Rev Input
BTU/HR
Air Flow Cabinet
Width
Configuration Nox Minor Rev
Rheem
80 - 80+ AFUE 1 - Single-stage
2 - Two-stage
V - Variable speed T - Constant Torque (X-13) P - PSC premium S - PSC standard
A - 1st Design
050 - 50,000 [15 kW] 075 - 75,000 [22 kW] 100 - 100,000 [29 kW] 125 - 125,000 [37 kW] 150 - 150,000 [44 kW]
3 - up to 3 ton 4 - 2 1/2 to 4 ton 5 - 3 1/2 up to 5 ton
14 - 14" 17 - 17.5" 21 - 21" 24 - 24.5"
M - Multi D - Down Z - Down &
zero clearance down flow
X - Low Nox
S - Standard
A - 1st Design
R
H 1 T 36
17
S T A N A A 000 *
Brand Product
Category
Stages of
Airflow
Motor Type Capacity
BTU/HR
Width Coil Size Metering
Device
Major
Series*
Controls Voltage Minor
Series**
Factory Heat
Cap
Option
Code
Rheem
H - Air
Handler
1 - Single-Stage 2 - Two-Stage M - Modulating
V - Variable
Speed
T - Constant
Torque
P - PSC
24 - 24,000 [7.03 kW] 36 - 36,000 [10.55 kW] 48 - 48,000 [14.07 kW] 60 - 60,000 [17.58 kW]
14 - 14" 17 - 17.5" 21 - 21" 24 - 24.5"
S - Standard
Eff.
M -Mid Eff. H - High Eff.
T - TEV E - EEV P - Piston
A - 1st Design C -Communicating
N -Non-comm
A - 1ph, 115/60 J - 1ph, 208-240/60 D - 3ph, 480/60
A - 1st Design 00 - no
factory heat with option code
*TBD
90%+ AFUE Gas Furnaces (For Reference) 80% AFUE Gas Furnaces (For Reference)
Air Handlers (For Reference)
[ ] Designates Metric Conversions
