Performance Data
RA13 Series
18
Performance Data @ AHRI Standard Conditions – Cooling (con’t.)
R801T Furnace Ratings
Outdoor
Unit
Furnace Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1342AC1 R801TA125524ZSA
RCF4824HTAM 41500 [12.2] 28100 [8.2] 13400 [3.9] 14.5 12 1150 [542.7] 7511593
RCF4824STAM 39500 [11.6] 27700 [8.1] 11800 [3.5] 14 11.5 1100 [519.1] 7511621
RA1342AJ1 R801TA075317ZSA RCF4821STAM 40000 [11.7] 29000 [8.5] 11000 [3.2] 13.5 11.5 1250 [589.9] 7511793
RA1342AJ1 R801TA075417MSA RCF4821STAM 40000 [11.7] 29100 [8.5] 10900 [3.2] 13.5 11.5 1275 [601.7] 7511794
RA1342AJ1 R801TA075521ZSA
RCF4821STAM 40000 [11.7] 28800 [8.4] 11200 [3.3] 13.5 11.5 1225 [578.1] 7511795
RCF4824HTAM 41500 [12.2] 28600 [8.4] 12900 [3.8] 14 11.5 1250 [589.9] 7511823
RCF4824STAM 40000 [11.7] 28800 [8.4] 11200 [3.3] 13.5 11.5 1225 [578.1] 7511851
RA1342AJ1 R801TA100521MSA
RCF4821STAM 40500 [11.9] 29900 [8.8] 10600 [3.1] 14 11.5 1325 [625.3] 7511796
RCF4824HTAM 42000 [12.3] 29600 [8.7] 12400 [3.6] 14.5 12 1350 [637.1] 7511824
RCF4824STAM 40500 [11.9] 29900 [8.8] 10600 [3.1] 14 11.5 1325 [625.3] 7511852
RA1342AJ1 R801TA100521ZSA
RCF4821STAM 40500 [11.9] 30300 [8.9] 10200 [3.0] 13.5 11.5 1425 [672.5] 7511797
RCF4824HTAM 42500 [12.5] 30700 [9.0] 11800 [3.5] 14 11.5 1450 [684.3] 7511825
RCF4824STAM 40500 [11.9] 30300 [8.9] 10200 [3.0] 13.5 11.5 1425 [672.5] 7511853
RA1342AJ1 R801TA125524MSA
RCF4824HTAM 42500 [12.5] 30400 [8.9] 12100 [3.5] 14.5 12 1400 [660.7] 7511826
RCF4824STAM 40500 [11.9] 30000 [8.8] 10500 [3.1] 14 11.5 1350 [637.1] 7511854
RA1342AJ1 R801TA125524ZSA
RCF4824HTAM 41500 [12.2] 28100 [8.2] 13400 [3.9] 14.5 12 1150 [542.7] 7511827
RCF4824STAM 39500 [11.6] 27700 [8.1] 11800 [3.5] 14 11.5 1100 [519.1] 7511855
RA1348AC1 R801TA075417MSA RCF4821STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13 11.5 1375 [648.9] 7508924
RA1348AC1 R801TA075521ZSA
RCF4821STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7508925
RCF4824HTAM 50000 [14.7] 34300 [10.1] 15700 [4.6] 13.5 11.5 1450 [684.3] 7508939
RCF4824STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7508970
RA1348AC1 R801TA100521MSA
RCF4821STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13.5 11.5 1375 [648.9] 7508926
RCF4824HTAM 50000 [14.7] 34200 [10.0] 15800 [4.6] 14 11.5 1425 [672.5] 7508940
RCF4824STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13.5 11.5 1375 [648.9] 7508973
RA1348AC1 R801TA100521ZSA
RCF4821STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7508927
RCF4824HTAM 49500 [14.5] 33700 [9.9] 15800 [4.6] 13.5 11.5 1425 [672.5] 7508941
RCF4824STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7508975
RA1348AC1 R801TA125524MSA
RCF4824HTAM 49500 [14.5] 33300 [9.8] 16200 [4.7] 14 11.5 1375 [648.9] 7508942
RCF4824STAM 47000 [13.8] 32500 [9.5] 14500 [4.2] 13.5 11.5 1325 [625.3] 7508977
RA1348AC1 R801TA125524ZSA
RCF4824HTAM 49500 [14.5] 33300 [9.8] 16200 [4.7] 13.5 11.5 1375 [648.9] 7508943
RCF4824STAM 47000 [13.8] 32500 [9.5] 14500 [4.2] 13 11.5 1325 [625.3] 7508979
RA1348AJ1 R801TA075417MSA RCF4821STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13 11.5 1375 [648.9] 7509149
RA1348AJ1 R801TA075521ZSA
RCF4821STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7509150
RCF4824HTAM 50000 [14.7] 34300 [10.1] 15700 [4.6] 13.5 11.5 1450 [684.3] 7509164
RCF4824STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7509189
RA1348AJ1 R801TA100521MSA
RCF4821STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13.5 11.5 1375 [648.9] 7509151
RCF4824HTAM 50000 [14.7] 34200 [10.0] 15800 [4.6] 14 11.5 1425 [672.5] 7509165
RCF4824STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13.5 11.5 1375 [648.9] 7509190
RA1348AJ1 R801TA100521ZSA
RCF4821STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7509152
RCF4824HTAM 49500 [14.5] 33700 [9.9] 15800 [4.6] 13.5 11.5 1425 [672.5] 7509166
RCF4824STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7509191
RA1348AJ1 R801TA125524MSA
RCF4824HTAM 49500 [14.5] 33300 [9.8] 16200 [4.7] 14 11.5 1375 [648.9] 7509167
RCF4824STAM 47000 [13.8] 32500 [9.5] 14500 [4.2] 13.5 11.5 1325 [625.3] 7509192
RA1348AJ1 R801TA125524ZSA
RCF4824HTAM 49500 [14.5] 33300 [9.8] 16200 [4.7] 13.5 11.5 1375 [648.9] 7509168
RCF4824STAM 47000 [13.8] 32500 [9.5] 14500 [4.2] 13 11.5 1325 [625.3] 7509193
RA1360AC1 R801TA075521ZSA
RCF6024HTAM 56000 [16.4] 38500 [11.3] 17500 [5.1] 13 11 1450 [684.3] 7509291
RCF6024STAM 56000 [16.4] 38500 [11.3] 17500 [5.1] 13 11 1450 [684.3] 7509315
