Rheem RA13 Series User Manual

Air
Performance Data
RA13 Series
20
Performance Data @ AHRI Standard Conditions – Cooling (con’t.)
R95T Furnace Ratings
Outdoor
Unit
Furnace Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1318AJ1 R95TA0401317MSA
RCF2417HTAM 18200 [5.3] 13100 [3.8] 5100 [1.5] 14.5 12 650 [306.8] 7507411
RCF2417MTAM 18200 [5.3] 13100 [3.8] 5100 [1.5] 14.5 12 650 [306.8] 7507426
RCF2417STAM 18200 [5.3] 13800 [4.0] 4400 [1.3] 14.5 12 650 [306.8] 7507442
RCF2421MTAM 18200 [5.3] 13100 [3.8] 5100 [1.5] 14.5 12 650 [306.8] 7507474
RA1324AJ1 R95TA0401317MSA
RCF2417HTAM 24400 [7.2] 17700 [5.2] 6700 [2.0] 14 11.5 875 [413.0] 7507615
RCF2417MTAM 24400 [7.2] 17700 [5.2] 6700 [2.0] 14 11.5 875 [413.0] 7507633
RCF2417STAM 24200 [7.1] 18400 [5.4] 5800 [1.7] 14 11.5 850 [401.2] 7507652
RCF2421MTAM 24400 [7.2] 17700 [5.2] 6700 [2.0] 14 11.5 875 [413.0] 7507693
RA1324AJ1 R95TA0601317MSA
RCF2417HTAM 24200 [7.1] 17500 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507616
RCF2417MTAM 24000 [7.0] 17300 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507634
RCF2417STAM 23400 [6.9] 17200 [5.0] 6200 [1.8] 14 11.5 700 [330.4] 7507653
RCF2421MTAM 24000 [7.0] 17300 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507694
RA1324AJ1 R95TA0701317MSA
RCF2417HTAM 24000 [7.0] 17300 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507617
RCF2417MTAM 24000 [7.0] 17300 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507635
RCF2417STAM 24000 [7.0] 18100 [5.3] 5900 [1.7] 13.5 11.5 825 [389.4] 7507654
RCF2421MTAM 24000 [7.0] 17300 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507695
RA1330AJ1 R95TA0401317MSA
RCF3617STAM 28600 [8.4] 21600 [6.3] 7000 [2.1] 14 11.5 925 [436.6] 7507850
RCF3621MTAM 30800 [9.0] 23300 [6.8] 7500 [2.2] 14.5 12 1100 [519.1] 7507870
RCF3621STAM 28800 [8.4] 21900 [6.4] 6900 [2.0] 14 11.5 950 [448.4] 7507901
RA1330AJ1 R95TA0601317MSA
RCF3617STAM 28800 [8.4] 22100 [6.5] 6700 [2.0] 13.5 11.5 1025 [483.7] 7507851
RCF3621MTAM 30000 [8.8] 21700 [6.4] 8300 [2.4] 14.5 12 900 [424.8] 7507871
RCF3621STAM 29000 [8.5] 22400 [6.6] 6600 [1.9] 13.5 11.5 1050 [495.5] 7507902
RA1330AJ1 R95TA0701317MSA
RCF3617STAM 28400 [8.3] 21400 [6.3] 7000 [2.1] 13.5 11.5 925 [436.6] 7507852
RCF3621MTAM 29800 [8.7] 21400 [6.3] 8400 [2.5] 14.5 12 875 [413.0] 7507872
RCF3621STAM 28400 [8.3] 21400 [6.3] 7000 [2.1] 13.5 11.5 925 [436.6] 7507903
RA1336AC1 R95TA0401317MSA
RCF3617STAM 35000 [10.3] 25000 [7.3] 10000 [2.9] 13.5 11.5 1050 [495.5] 7508195
RCF3621MTAM 37800 [11.1] 26700 [7.8] 11100 [3.3] 14 11.5 1175 [554.5] 7508215
RCF3621STAM 35200 [10.3] 25300 [7.4] 9900 [2.9] 13.5 11.5 1075 [507.3] 7508246
RA1336AC1 R95TA0601317MSA
RCF3617STAM 34800 [10.2] 24500 [7.2] 10300 [3.0] 13 11.5 1000 [471.9] 7508196
RCF3621MTAM 36800 [10.8] 25100 [7.4] 11700 [3.4] 14 11.5 1050 [495.5] 7508216
RCF3621STAM 34800 [10.2] 24700 [7.2] 10100 [3.0] 13 11.5 1025 [483.7] 7508247
RA1336AC1 R95TA0701317MSA
RCF3617STAM 34600 [10.1] 24500 [7.2] 10100 [3.0] 13 11 1025 [483.7] 7508197
RCF3621MTAM 37000 [10.8] 25500 [7.5] 11500 [3.4] 14 11.5 1075 [507.3] 7508217
RCF3621STAM 34200 [10.0] 23700 [6.9] 10500 [3.1] 13 11.5 925 [436.6] 7508248
RA1336AC1 R95TA1151524MSA
RCF3624HTAM 39500 [11.6] 29100 [8.5] 10400 [3.0] 14 11.5 1325 [625.3] 7508277
RCF3624MTAM 38000 [11.1] 27400 [8.0] 10600 [3.1] 13.5 11.5 1275 [601.7] 7508304
RA1336AJ1 R95TA0401317MSA
RCF3617STAM 35000 [10.3] 25000 [7.3] 10000 [2.9] 13.5 11.5 1050 [495.5] 7508561
RCF3621MTAM 37800 [11.1] 26700 [7.8] 11100 [3.3] 14 11.5 1175 [554.5] 7508581
RCF3621STAM 35200 [10.3] 25300 [7.4] 9900 [2.9] 13.5 11.5 1075 [507.3] 7508612
RA1336AJ1 R95TA0601317MSA
RCF3617STAM 34800 [10.2] 24500 [7.2] 10300 [3.0] 13 11.5 1000 [471.9] 7508562
RCF3621MTAM 36800 [10.8] 25100 [7.4] 11700 [3.4] 14 11.5 1050 [495.5] 7508582
RCF3621STAM 34800 [10.2] 24700 [7.2] 10100 [3.0] 13 11.5 1025 [483.7] 7508613
RA1336AJ1 R95TA0701317MSA
RCF3617STAM 34600 [10.1] 24500 [7.2] 10100 [3.0] 13 11 1025 [483.7] 7508563
RCF3621MTAM 37000 [10.8] 25500 [7.5] 11500 [3.4] 14 11.5 1075 [507.3] 7508583
RCF3621STAM 34200 [10.0] 23700 [6.9] 10500 [3.1] 13 11.5 925 [436.6] 7508614
RA1336AJ1 R95TA1151524MSA
RCF3624HTAM 39500 [11.6] 29100 [8.5] 10400 [3.0] 14 11.5 1325 [625.3] 7508643
RCF3624MTAM 38000 [11.1] 27400 [8.0] 10600 [3.1] 13.5 11.5 1275 [601.7] 7508670
RA1342AC1 R95TA0401317MSA RCF4821STAM 39500 [11.6] 28100 [8.2] 11400 [3.3] 13.5 11.5 1175 [554.5] 7511564
