Performance Data
RA13 Series
Performance Data @ AHRI Standard Conditions – Cooling (con’t.)
ROLA Furnace Ratings
Outdoor
Unit
Furnace Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1336AJ1 ROLA-070E04
RCF3617STAM 35600 [10.4] 26100 [7.6] 9500 [2.8] 13.5 11.5 1175 [554.5] 7508575
RCF3621MTAM 37200 [10.9] 25500 [7.5] 11700 [3.4] 14.5 12 1025 [483.7] 7508604
RCF3621STAM 35800 [10.5] 26300 [7.7] 9500 [2.8] 13.5 11.5 1175 [554.5] 7508635
RCF3624HTAM 38000 [11.1] 26200 [7.7] 11800 [3.5] 15.1 12.5 1025 [483.7] 7508662
RCF3624MTAM 37200 [10.9] 25500 [7.5] 11700 [3.4] 14.5 12 1025 [483.7] 7508689
RA1336AJ1 ROLA-115E05
RCF3621MTAM 38000 [11.1] 27100 [7.9] 10900 [3.2] 14.5 12 1200 [566.3] 7508605
RCF3621STAM 35800 [10.5] 26400 [7.7] 9400 [2.8] 13.5 11.5 1200 [566.3] 7508636
RCF3624HTAM 39000 [11.4] 28000 [8.2] 11000 [3.2] 15.1 12.5 1200 [566.3] 7508663
RCF3624MTAM 38000 [11.1] 27100 [7.9] 10900 [3.2] 14.5 12 1200 [566.3] 7508690
RA1342AC1 ROLA-070E03
RCF4821STAM 40000 [11.7] 28600 [8.4] 11400 [3.3] 13.5 11.5 1175 [554.5] 7511586
RCF4824HTAM 41500 [12.2] 28200 [8.3] 13300 [3.9] 14 11.5 1175 [554.5] 7511613
RCF4824STAM 40000 [11.7] 28600 [8.4] 11400 [3.3] 13.5 11.5 1175 [554.5] 7511640
RA1342AC1 ROLA-070E04
RCF4821STAM 40500 [11.9] 30100 [8.8] 10400 [3.0] 13.5 11.5 1375 [648.9] 7511587
RCF4824HTAM 42000 [12.3] 29700 [8.7] 12300 [3.6] 14 11.5 1375 [648.9] 7511614
RCF4824STAM 40500 [11.9] 30100 [8.8] 10400 [3.0] 13.5 11.5 1375 [648.9] 7511641
RA1342AC1 ROLA-115E05
RCF4821STAM 40500 [11.9] 30300 [8.9] 10200 [3.0] 13.5 11.5 1400 [660.7] 7511588
RCF4824HTAM 41500 [12.2] 28300 [8.3] 13200 [3.9] 14.5 12 1200 [566.3] 7511615
RCF4824STAM 40500 [11.9] 30300 [8.9] 10200 [3.0] 13.5 11.5 1400 [660.7] 7511642
RA1342AJ1 ROLA-070E03
RCF4821STAM 40000 [11.7] 28600 [8.4] 11400 [3.3] 13.5 11.5 1175 [554.5] 7511820
RCF4824HTAM 41500 [12.2] 28200 [8.3] 13300 [3.9] 14 11.5 1175 [554.5] 7511847
RCF4824STAM 40000 [11.7] 28600 [8.4] 11400 [3.3] 13.5 11.5 1175 [554.5] 7511874
RA1342AJ1 ROLA-070E04
RCF4821STAM 40500 [11.9] 30100 [8.8] 10400 [3.0] 13.5 11.5 1375 [648.9] 7511821
RCF4824HTAM 42000 [12.3] 29700 [8.7] 12300 [3.6] 14 11.5 1375 [648.9] 7511848
RCF4824STAM 40500 [11.9] 30100 [8.8] 10400 [3.0] 13.5 11.5 1375 [648.9] 7511875
RA1342AJ1 ROLA-115E05
RCF4821STAM 40500 [11.9] 30300 [8.9] 10200 [3.0] 13.5 11.5 1400 [660.7] 7511822
RCF4824HTAM 41500 [12.2] 28300 [8.3] 13200 [3.9] 14.5 12 1200 [566.3] 7511849
RCF4824STAM 40500 [11.9] 30300 [8.9] 10200 [3.0] 13.5 11.5 1400 [660.7] 7511876
RA1348AC1 ROLA-070E04
RCF4821STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13 11.5 1375 [648.9] 7508937
RCF4824HTAM 49500 [14.5] 33300 [9.8] 16200 [4.7] 13.5 11.5 1375 [648.9] 7508964
RCF4824STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13 11.5 1375 [648.9] 7509014
RA1348AC1 ROLA-115E05
RCF4821STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7508938
RCF4824HTAM 49500 [14.5] 33500 [9.8] 16000 [4.7] 13.5 11.5 1400 [660.7] 7508966
RCF4824STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7509016
RA1348AJ1 ROLA-070E04
RCF4821STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13 11.5 1375 [648.9] 7509162
RCF4824HTAM 49500 [14.5] 33300 [9.8] 16200 [4.7] 13.5 11.5 1375 [648.9] 7509186
RCF4824STAM 47000 [13.8] 32800 [9.6] 14200 [4.2] 13 11.5 1375 [648.9] 7509208
RA1348AJ1 ROLA-115E05
RCF4821STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7509163
RCF4824HTAM 49500 [14.5] 33500 [9.8] 16000 [4.7] 13.5 11.5 1400 [660.7] 7509187
RCF4824STAM 47000 [13.8] 33000 [9.7] 14000 [4.1] 13 11.5 1400 [660.7] 7509209
RA1360AC1 ROLA-115E05
RCF6024HTAM 56000 [16.4] 39600 [11.6] 16400 [4.8] 13 11 1600 [755.1] 7509312
RCF6024STAM 56000 [16.4] 39600 [11.6] 16400 [4.8] 13 11 1600 [755.1] 7509335
RA1360AJ1 ROLA-115E05
RCF6024HTAM 56000 [16.4] 39600 [11.6] 16400 [4.8] 13 11 1600 [755.1] 7509434
RCF6024STAM 56000 [16.4] 39600 [11.6] 16400 [4.8] 13 11 1600 [755.1] 7509457
[ ] Designates Metric Conversions

Rheem RA13 Series Specifications

General

Brand	Rheem
Model	RA13 Series
Category	Air Conditioner
Language	English
