39
Air
Performance Data
RA13 Series
Performance Data @ AHRI Standard Conditions – Cooling (con’t.)
Air Handler Ratings
Outdoor
Unit
Air Handler
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1336AJ1
RBHP-21 36400 [10.7] 24500 [7.2] 11900 [3.5] 14 11.5 1200 [566.3] 7508556
RH1P3017STAN 34200 [10.0] 23800 [7.0] 10400 [3.0] 13 11 950 [448.4] 7508907
RH1T3617STAN 35200 [10.3] 24900 [7.3] 10300 [3.0] 14 11.5 1000 [471.9] 7508908
RH1T3621MTAN 38000 [11.1] 27000 [7.9] 11000 [3.2] 14.5 12 1175 [554.5] 7508909
RHLL-HM3617 35600 [10.4] 22900 [6.7] 12700 [3.7] 14 11.5 1000 [471.9] 7508915
RHLL-HM3821 36800 [10.8] 24800 [7.3] 12000 [3.5] 14 11.5 1175 [554.5] 7508916
RHML-HM3621 36000 [10.6] 23400 [6.9] 12600 [3.7] 14.5 12 1050 [495.5] 7508917
RHSL-HM3017 34600 [10.1] 21800 [6.4] 12800 [3.8] 13 11 950 [448.4] 7508921
RH1V3617STAN 36000 [10.6] 26800 [7.9] 9200 [2.7] 13.5 11.5 1225 [578.1] 7508910
RH1V3621MTAN 38000 [11.1] 27100 [7.9] 10900 [3.2] 14.5 12 1200 [566.3] 7508911
RH2V3624HTAC 39000 [11.4] 28000 [8.2] 11000 [3.2] 15 12.5 1200 [566.3] 7508912
RHKL-HM3617 35400 [10.4] 22800 [6.7] 12600 [3.7] 14 11.5 1025 [483.7] 7508913
RHKL-HM3821 36000 [10.6] 23300 [6.8] 12700 [3.7] 14.5 12 1000 [471.9] 7508914
RHPL-HM3621 36600 [10.7] 24800 [7.3] 11800 [3.5] 13.5 11.5 1225 [578.1] 7508918
RHPL-HM3821 36600 [10.7] 24500 [7.2] 12100 [3.5] 14 11.5 1150 [542.7] 7508919
RHPN-HM3624 39000 [11.4] 27800 [8.1] 11200 [3.3] 15 12.5 1200 [566.3] 7508920
RA1342AC1
RBHP-24 40500 [11.9] 26900 [7.9] 13600 [4.0] 14 11.5 1400 [660.7] 7511557
RH1T4821STAN 41000 [12.0] 30800 [9.0] 10200 [3.0] 14 11.5 1400 [660.7] 7511783
RH2T4824MTAN 42500 [12.5] 30400 [8.9] 12100 [3.5] 14.5 12 1400 [660.7] 7511785
RHLL-HM4821 40000 [11.7] 26400 [7.7] 13600 [4.0] 13.5 11.5 1400 [660.7] 7511788
RHML-HM4824 43000 [12.6] 30800 [9.0] 12200 [3.6] 14.5 12 1400 [660.7] 7511789
RH1V4821STAN 41000 [12.0] 30800 [9.0] 10200 [3.0] 13.5 11.5 1400 [660.7] 7511784
RH2V4824HTAC 43500 [12.7] 32600 [9.6] 10900 [3.2] 14 11.5 1600 [755.1] 7511786
RHKL-HM4821 40000 [11.7] 26400 [7.7] 13600 [4.0] 13.5 11.5 1400 [660.7] 7511787
RHPN-HM4824 43500 [12.7] 32400 [9.5] 11100 [3.3] 14.5 12 1600 [755.1] 7511790
RA1342AJ1
RBHP-24 40500 [11.9] 26900 [7.9] 13600 [4.0] 14 11.5 1400 [660.7] 7511791
RH1T4821STAN 41000 [12.0] 30800 [9.0] 10200 [3.0] 14 11.5 1400 [660.7] 7512017
RH2T4824MTAN 42500 [12.5] 30400 [8.9] 12100 [3.5] 14.5 12 1400 [660.7] 7512019
RHLL-HM4821 40000 [11.7] 26400 [7.7] 13600 [4.0] 13.5 11.5 1400 [660.7] 7512022
RHML-HM4824 43000 [12.6] 30800 [9.0] 12200 [3.6] 14.5 12 1400 [660.7] 7512023
RH1V4821STAN 41000 [12.0] 30800 [9.0] 10200 [3.0] 13.5 11.5 1400 [660.7] 7512018
RH2V4824HTAC 43500 [12.7] 32600 [9.6] 10900 [3.2] 14 11.5 1600 [755.1] 7512020
RHKL-HM4821 40000 [11.7] 26400 [7.7] 13600 [4.0] 13.5 11.5 1400 [660.7] 7512021
RHPN-HM4824 43500 [12.7] 32400 [9.5] 11100 [3.3] 14.5 12 1600 [755.1] 7512024
RA1348AC1
RBHP-24 48000 [14.1] 31700 [9.3] 16300 [4.8] 13.5 11.5 1600 [755.1] 7508922
RH1T4821STAN 47500 [13.9] 33500 [9.8] 14000 [4.1] 13.5 11.5 1400 [660.7] 7509131
RH1T4824STAN 48000 [14.1] 35000 [10.3] 13000 [3.8] 13.5 11.5 1550 [731.5] 7509132
RH2T4824MTAN 50000 [14.7] 34000 [10.0] 16000 [4.7] 14 11.5 1400 [660.7] 7509135
RHLL-HM4821 47500 [13.9] 31300 [9.2] 16200 [4.7] 13 11.5 1600 [755.1] 7509140
RHLL-HM4824 47500 [13.9] 31500 [9.2] 16000 [4.7] 13.5 11.5 1625 [766.9] 7509141
RHLL-HM6024 52000 [15.2] 38500 [11.3] 13500 [4.0] 14 11.5 1800 [849.5] 7509142
RHML-HM4824 50000 [14.7] 33800 [9.9] 16200 [4.7] 14 11.5 1400 [660.7] 7509143
RH1V4821STAN 48000 [14.1] 35100 [10.3] 12900 [3.8] 13 11.5 1575 [743.3] 7509133
RH1V4824STAN 48500 [14.2] 36000 [10.6] 12500 [3.7] 13.5 11.5 1625 [766.9] 7509134
RH2V4824HTAC 51000 [14.9] 36400 [10.7] 14600 [4.3] 14 11.5 1600 [755.1] 7509136
RHKL-HM4821 46500 [13.6] 29100 [8.5] 17400 [5.1] 13 11.5 1400 [660.7] 7509137
[ ] Designates Metric Conversions
