Dimensional Data
RGRS/RGRT Series
6
Upflow Models
MODEL
RGRS/RGRT-
A B C D E F
LEFT
SIDE
MINIMUM CLEARANCE (IN.) [mm]
SHIP
WGTS.
[kg]
RIGHT
SIDE
BACK TOP FRONT VENT
04 17
1
/2 [445] 16
11
/32 [415] 15
5
/8 [397] 2 [51] 15 [422] 13
25
/32 [352] 0 0 0 1 [25] 2 [51] 0 111 [50]
06
17
1
/2 [445] 16
11
/32 [415] 15
5
/8 [397]
2 [51]
15 [422] 13
25
/32 [352]
0 0 0 1 [25] 2 [51] 0 117 [53]
07EM 17
1
/2 [445] 16
11
/32 [415] 15
5
/8 [397] 2 [51] 15 [422] 13
25
/32 [352] 0 0 0 1 [25] 2 [51] 0 123 [56]
07EY
21 [533] 19
27
/32 [504] 19
1
/8 [487]
2 [51]
18
1
/2 [511] 17
9
/32 [441]
0 0 0 1 [25] 2 [51] 0 123 [56]
09 21 [533] 19
27
/32 [504] 19
1
/8 [487] 2 [51] 18
1
/2 [511] 17
9
/32 [441] 0 0 0 1 [25] 2 [51] 0 148 [67]
10
21 [533] 19
27
/32 [504] 19
1
/8 [487]
2 [51]
18
1
/2 [511] 17
9
/32 [441]
0 0 0 1 [25] 2 [51] 0 152 [69]
12 24
1
/
2 [622]
23
11
/
32 [593]
22
5
/
8 [575]
2 [51] 22 [600] 20
25
/
32 [530]
0 0 0 1 [25] 2 [51] 0 160 [73]
