21
4.9 ELECTRIC HEAT ELECTRICAL DATA: (-)H1V - continued
RXBH-1724?05J 3.6/4.8 1/60 1-4.8 SINGLE 17.3/20.0 4.4 28/31 30/35
RXBH-1724?07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 4.4 38/43 40/45
RXBH-1724?10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 4.4 49/56 50/60
RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60.0 4.4 71/81 80/90
3.6/4.8 1/60 1-4.8 MULTIPLE CKT1 17.3/20.0 4.4 28/31 30/35
RXBH-1724A15J
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0 44/50 45/50
RXBH-1724A18J 12.8/17 1/60 4-4.26 SINGLE 61.6/70.8 4.4 83/94 90/100
6.4/8.5 1/60 2-4.26 MULTIPLE CKT 1 30.8/35.4 4.4 44/50 45/50
RXBH-1724A18J
6.4/8.5 1/60 2-4.26 MULTIPLE CKT 2 30.8/35.4 0 39/45 40/45
RXBH-24A20J 14.4/19.2 1/60 4-4.8 SINGLE 69.2/80 4.4 93/106 100/110
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 1 34.6/40.0 4.4 49/56 50/60
RXBH-24A20J
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0 44/50 45/50
RXBH-24A25J 18.0/24.0 1/60 6-4.0 SINGLE 86.4/99.9 4.4 114/131 125/150
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 1 28.8/33.3 4.4 42/48 45/50
RXBH-24A25J 6.0/8.0 1/60 2-4.0 MULTIPLE CKT 2 28.8/33.3 0 36/42 40/45
4824ST 6.0/8.0 1/60 2-4.0 MULTIPLE CKT 3 28.8/33.3 0 36/42 40/45
6024ST RXBH-24A30J 21.6/28.8 1/60 6-4.8 SINGLE 103.8/120. 4.4 136/156 150/175
(1800 CFM only)
RXBH-24A30J
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 1 34.6/40.0 4.4 49/56 50/60
(5-ton only) 7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0 44/50 45/50
(1800 CFM only)
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 3 34.6/40.0 0 44/50 45/50
RXBH-1724A07C 5.4/7.2 3/60 3-2.4 SINGLE 15.0/17.3 4.4 25/28 25/30
RXBH-1724A10C 7.2/9.6 3/60 3-3.2 SINGLE 20.0/23.1 4.4 31/35 35/35
RXBH-1724A15C 10.8/14.4 3/60 3-4.8 SINGLE 30.0/34.6 4.4 43/49 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-2.84 SINGLE 35.6/41.0 4.4 50/57 50/60
14.4/19.2 3/60 3-3.2 SINGLE 40.0/46.2 4.4 56/64 60/70
RXBH-24A20C* 7.2/9.6 3/60 3-3.2 MULTIPLE CKT 1 20.0/23.1 4.4 31/35 35/35
7.2/9.6 3/60 3-3.2 MULTIPLE CKT 2 20.0/23.1 0 25/29 25/30
RXBH-24A25C* 18.0/24.0 3/60 6-4.0 SINGLE 50.0/57.8 4.4 68/78 70/80
9.0/12.0 3/60 3-4.0 MULTIPLE CKT 1 25.0/28.9 4.4 37/42 40/45
RXBH-24A25C
9.0/12.0 3/60 3-4.0 MULTIPLE CKT 2 25.0/28.9 0 32/37 35/40
RXBH-24A30C*
21.6/28.8 3/60 6-4.8 SINGLE 60.0/69.4 4.4 81/93 90/100
(1800 CFM only)
RXBH-24A30C
10.8/14.4 3/60 3-4.8 MULTIPLE CKT 1 30.0/34.7 4.4 43/50 45/50
(5-ton only)
10.8/14.4 3/60 3-4.8 MULTIPLE CKT 2 30.0/34.7 0 38/44 40/45
(1800 CFM only)
AIR-HANDLER
MODEL
(-)H1V
HEATER
MODEL
NO.
HEATER
KW
208/240V
PH/HZ
NO.
ELEMENTS
- KW PER
TYPE SUPPLY
CIRCUIT
SINGLE CIRCUIT
MULTIPLE CIRCUIT
CIRCUIT
AMPS.
MOTOR
AMPACITY
MINIMUM
CIRCUIT
AMPACITY
MAXIMUM
CIRCUIT
PROTECTION
NOTES:
* Values only. No single point kit available.
Electric heater BTUH - (heater watts + motor watts) x 3.414 (see airflow table for motor watts.)
Supply circuit protective devices may be fuses or “HACR” type circuit breakers.
Largest motor load is included in single circuit and multiple circuit 1.
If non-standard fuse size is specified, use next size larger fuse size.
J Voltage (230V) single phase air handler is designed to be used with single or three phase 230 volt electric heaters. In the case
of connecting 3-phase power to the air handler terminal block without the heater, bring only two leads to the terminal block. Cap,
insulate and fully secure the third lead.
If the kit is listed under both single and multiple circuits, the kit is shipped from factory as multiple circuits. For single phase appli-
cation, Jumper bar kit RXBJ-A21 and RXBJ-A31 can be used to convert multiple circuits to a single supply circuit. Refer to
Accessory Section for details.
The airflow for continuous fan is set 50% of the cooling airflow.
?Heater kits connection type. A=Breaker B=Terminal Block C=Disconnect Pull Out
