12
GENERAL DATA—RJNA- SERIES
Model RJNA- Series A048JK A060CK A060CL A060CM
Cooling Performance
1
Gross Cooling Capacity Btu [kW] 49,500 [14.5] 63,500 [18.6] 64,000 [18.8] 64,000 [18.8]
EER/SEER
2
11.65/13 11.55/13 11.55/13 11.55/13
Nominal CFM/ARI Rated CFM [L/s] 1600/1600 [755/755] 2000/2000 [944/944] 2000/2000 [944/944] 2000/2000 [944/944]
ARI Net Cooling Capacity Btu [kW] 47,000 [13.8] 61,500 [18] 61,500 [18] 61,500 [18]
Net Sensible Capacity Btu [kW] 34,700 [10.2] 43,800 [12.8] 43,800 [12.8] 43,800 [12.8]
Net System Power kW 4 5.3 5.3 5.3
Heating Performance (Heat Pumps)
Heating Temp. Btuh [kW] Rating 46,500 [13.6] 60,500 [17.7] 60,500 [17.7] 60,500 [17.7]
System Power KW/COP 3.9/3.5 5/3.5 5/3.5 5/3.5
Low Temp. Btuh [kW] Rating 27,800 [8.1] 36,000 [10.5] 36,000 [10.5] 36,000 [10.5]
Net Weight lbs. [kg] 535 [243] 565 [256] 565 [256] 565 [256]
System Power KW/COP 3.7/2.22 4.4/2.3 4.4/2.3 4.4/2.3
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
HSPF (Btu/Watts-hr) 7.7 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)
3
83 83 83 83
Outdoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Net Latent Capacity Btu [kW] 12,300 [3.6] 17,700 [5.2] 17,700 [5.2] 17,700 [5.2]
Indoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan—Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/11x9 [279.4x228.6] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Direct/3 Direct/2 Belt/Variable Belt/Variable
No. Motors 1 1 1 1
Motor HP 1/2 1 3/4 1
Motor RPM 1075 1100 1725 1725
Motor Frame Size 48 48 56 56
Filter—Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(No.) Size Recommended in. [mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 206 [5840] 184 [5216] 184 [5216] 184 [5216]
Weights
Ship Weight lbs. [kg] 550 [249] 580 [263] 580 [263] 580 [263]
CONTINUED
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 14 for Notes.
[ ] Designates Metric Conversions
