GENERAL DATA - RKNA MODELS
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
Model RKNA- Series A036CM08E A036CM12E A036DK08E A036DK12E
Cooling Performance
1
Continued ->
Gross Cooling Capacity Btu [kW] 37,400 [10.96] 37,400 [10.96] 37,400 [10.96] 37,400 [10.96]
EER/SEER
2
11.7/13 11.7/13 11.7/13 11.7/13
Nominal CFM/ARI Rated CFM [L/s] 1200/1200 [566/566] 1200/1200 [566/566] 1200/1200 [566/566] 1200/1200 [566/566]
ARI Net Cooling Capacity Btu [kW] 36,000 [10.55] 36,000 [10.55] 36,000 [10.55] 36,000 [10.55]
Net Sensible Capacity Btu [kW] 26,400 [7.74] 26,400 [7.74] 26,400 [7.74] 26,400 [7.74]
Net Latent Capacity Btu [kW] 9,600 [2.81] 9,600 [2.81] 9,600 [2.81] 9,600 [2.81]
Net System Power kW 3.08 3.08 3.08 3.08
Heating Performance (Package Gas/Electric)
Heating Input Btu [kW] 80,000 [23.44] 120,000 [35.16] 80,000 [23.44] 120,000 [35.16]
Heating Output Btu [kW] 64,800 [18.99] 97,200 [28.48] 64,800 [18.99] 97,200 [28.48]
Temperature Rise Range ºF [ºC] 30-60 [16.7/33.3] 50-80 [27.8/44.4] 30-60 [16.7/33.3] 50-80 [27.8/44.4]
AFUE % 80808080
Steady State Efficiency (%) 81 81 81 81
No. Burners 4 6 4 6
No. Stages 1111
Gas Connection Pipe Size in. [mm] 0.5 [12.7] 0.5 [12.7] 0.5 [12.7] 0.5 [12.7]
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)
78 78 78 78
Outdoor Coil - Fin T
y
pe Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.91 [1.57] 16.91 [1.57] 16.91 [1.57] 16.91 [1.57]
Rows / FPI [FPcm] 1 / 22 [9] 1 / 22 [9] 1 / 22 [9] 1 / 22 [9]
Indoor Coil - Fin T
y
pe Corrugated Corrugated Corrugated Corrugated
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.17 [0.48] 5.17 [0.48] 5.17 [0.48] 5.17 [0.48]
Rows / FPI [FPcm] 2 / 17 [7] 2 / 17 [7] 2 / 17 [7] 2 / 17 [7]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/0.75 [19.05] 1/0.75 [19.05] 1/0.75 [19.05] 1/0.75 [19.05]
Outdoor Fan - T
y
pe Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 3680 [1737] 3680 [1737] 3680 [1737] 3680 [1737]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan - T
y
pe FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Belt/Variable Belt/Variable Direct/3 Direct/3
No. Motors 1 1 1 1
Motor HP 1/2 1/2 1/2 1/2
Motor RPM 1725 1725 1075 1075
Motor Frame Size 48 48 48 48
Filter - T
y
pe Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(NO.) Size Recommended in. [mm x mm x mm] (1)1x16x25 [25x406x635] (1)1x16x25 [25x406x635] (1)1x16x25 [25x406x635] (1)1x16x25 [25x406x635]
(1)1x16x25 [25x406x635] (1)1x16x25 [25x406x635] (1)1x16x25 [25x406x635] (1)1x16x25 [25x406x635]
Refri
g
erant Char
g
e Oz. [
g
] 93 [2637] 93 [2637] 93 [2637] 93 [2637]
Wei
g
hts
Net Weight lbs. [kg] 543 [246] 543 [246] 543 [246] 543 [246]
Ship Wei
g
ht lbs. [k
g
] 550 [249] 550 [249] 550 [249] 550 [249]
