Rheem RKNA SERIES User Manual

43
GENERAL DATA - RKNA MODELS
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
Model RKNA- Series A060JK13E A060JK13X
Cooling Performance
1
Gross Cooling Capacity Btu [kW] 60,000 [17.58] 60,000 [17.58]
EER/SEER
2
11.6/13 11.6/13
Nominal CFM/ARI Rated CFM [L/s] 2000/1900 [897/897] 2000/1900 [897/897]
ARI Net Cooling Capacity Btu [kW] 58,000 [16.99] 58,000 [16.99]
Net Sensible Capacity Btu [kW] 42,000 [12.31] 42,000 [12.31]
Net Latent Capacity Btu [kW] 16,000 [4.69] 16,000 [4.69]
Net System Power kW 5 5
Heating Performance (Package Gas/Electric)
3
Heating Input Btu [kW] 135,000 [39.56] 135,000 [39.56]
Heating Output Btu [kW] 106,500 [31.2] 106,500 [31.2]
Temperature Rise Range ºF [ºC] 40-70 [22.2/38.9] 40-70 [22.2/38.9]
AFUE % 80 80
Steady State Efficiency (%) 81 81
No. Burners 6 6
No. Stages 1 1
Gas Connection Pipe Size in. [mm] 0.5 [12.7] 0.5 [12.7]
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)
83 83
Outdoor Coil - Fin T
y
pe Louvered Louvered
Tube Type Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9]
Indoor Coil - Fin T
y
pe Corrugated Corrugated
Tube Type Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.17 [0.48] 5.17 [0.48]
Rows / FPI [FPcm] 3 / 15 [6] 3 / 15 [6]
Refrigerant Control TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/0.75 [19.05] 1/0.75 [19.05]
Outdoor Fan - T
y
pe Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1
CFM [L/s] 3930 [1855] 3930 [1855]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075
Indoor Fan - T
y
pe FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Direct/3 Direct/3
No. Motors 1 1
Motor HP
Motor RPM 1075 1075
Motor Frame Size 48 48
Filter - T
y
pe Disposable Disposable
Furnished Yes Yes
(NO.) Size Recommended in. [mm x mm x mm] (1)1x16x25 [25x406x635] (1)1x16x25 [25x406x635]
(1)1x16x25 [25x406x635] (1)1x16x25 [25x406x635]
Refri
g
erant Char
g
e Oz. [
g
] 160 [4536] 160 [4536]
Wei
g
hts
Net Weight lbs. [kg] 597 [271] 597 [271]
Ship Wei
g
ht lbs. [k
g
] 604 [274] 604 [274]
1
1
NOTES:
1. Cooling Performance is rated at 95° F ambient, 80° F entering dry bulb, 67° F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity
is net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Units are certified in accordance with the Unitary Air Conditioner
Equipment certification program, which is based on ARI Standard 210/240 or 360.
2. EER and/or SEER are rated at ARI conditions and in accordance with DOE test procedures.
3. Heating Performance limit settings and rating data were established and approved under laboratory test conditions using American Nationa
l Standard Institute standards.
Ratings shown are for elevations up to 2000 feet. For elevations above 2000 feet, ratings should be reduced at the rate of 4% for each 1000 feet above sea level.
