Errorcode Meaning Condition
WaterMixingValveAbnormality
(Manualrestore)
①Occursmanualrestoreerror.
②Waterleakageoccursaround
thewatermixingvalve.
③Abnormalvalveoperation.
Failureevent
Operationofproductisstoppedoncedetectingwaterleakage.Thetemperatureofhotwaterisnot
constant.
Checkpoint
④IfaboveissuesoperateswellreplaceCircuitBoard.
①Checkerrorcodesignafterturningo󰘯andonthepower.
③Ifabove①,②operatesnormallyreplacevalve
[WaterMixingValve]
DHMYPhase(black):connector①
DHMYPhase(brown):connector②
DHMXPhase(red):connector③
DHMXPhase(orange):connector④
GND(yellow):connector⑤
DHMPositionsensor(green):connector⑥
Flow2sensor(blue):connector⑦
DC14V(white):connector⑧
①②③④ ⑤⑥⑦⑧
