Rheem RTGH-RH10DV - Water Mixing Valve

85
MaincomponentsReplacementInstructions
1.Closethegasshuto󰘯valve.
2.Turnthepowero󰘯.
3. Placeabucketundertheunitandragundervalve
tocollecttheresidualwaterfromthewaterheater.
4.Disconnecttheelectricalpowertothewaterheater.
5.ClosethebothDHWinletandhotwatervalve.
6.OpentheHotwaterfaucetscompletely.
7.Disconnectalltheelectricalconnectiontothecircuit
board.LoosenthethreescrewstoremovetheCircuit
BoardandCircuitBoardBracketinonepiece.
8.Separateconnectorconnectedwithwatermixing
valve.
9.Removetwoclipsconnectedwithwatermixing
valveandoutletpipe.
10.Separatewatermixingvalveandoutletpipe.
11. Removethewatermixingvalveandreplacewithnew
sparepart.Checktheo-ringsfordamage,ifdamaged,
replacewithnewo-rings.
12.Assembleinthereverseorderasthepartwas
removed.
13.Switchwatervalvetoopen.
14.Switchmanualpowerswitchtoopen.
15.Switchmaingasvalvetoopen.
16.Testoperation.
Chapter5ReplacementInstructions
8.WaterMixingValve
