Triton Service Manual SVC1020T ; Rev 4

80 and 100 gallon chassis

Triton Servicing: Burner Assembly

9. To replace the burner, take the new burner and gasket and attach using the screws provided.

10. Make sure to attach the blower to the burner in the same orientation as it had been attached previously.

11. Insert the burner assembly back into the top of the water heater making sure that the air intake and the gas

valve are pointing towards the back.

12. Bolt the burner assembly back into place and make sure to tighten all of the bolts using the ratchet and half

inch socket.
