Note 2: the stop command is not to be considered a safety command that can be bypassed
in this mode. Therefore, when pressed or damaged, it will not allow any movement
of the gate.
The hold-to-run mode is only an emergency operation which must be activated for a
very short period and with the complete installation at sight so to have a secure and
safe control of the system. As soon as possible however, the failing safety devices
must be repaired and activated.
VISUAL AND SOUND ALARMS
BLINKER
N.B.: This control panel can power ONLY BLINKERS WITH BLINKING CIRCUIT (ACG7061) with
lamps up to 24V and 20W.
PRE-BLINKING
DIP 5 - OFF => motor and blinker start simultaneously.
DIP 5 - ON => blinker starts 3 seconds before the motor.
BUZZER
It has the task to signal the intervention of the security, the anomalies and the memorization
and cancellation of the radio codes.
SIGNAL - 24Vdc GATE OPEN WARNING LIGHT (COM A+/SIGNAL-)
Signals when the gate is open, partially open or not closed completely. It turns off only when
the gate is completely closed.
During opening, it flashes slowly.
When the gate is stationary or opened, it is permanently on.
During closing, it flashes quickly
N.B.: Max 3 W. If warning lights are in excess, the control panel processes will be
endangered with possible stop of all operations.
OPERATION AFTER A BLACK-OUT (WITHOUT BATTERIES)
When the power supply comes back the DL1 led turns on and remains on for all the time the
gate stays open. The led will turn off only once the gate is completely closed.
It is recommended to fully open the gate. Let the gate close by itself or with automatic
closing, or wait until the blinker stops flashing before commanding it to close.
This will allow the gate to realign. If, motors were released and moved from the normal
position when closed during the blackout, the first movement after power returns must be
complete.
If the black out occurs when the gate is still moving or when the gate is open and the first
command sent after the black out is a closing command, the closing of the gate will be
carried out with a total delay between the two gate leaves. Therefore, first the leaf M2 will
close completely; once it is off, M1 will start closing. This separate movement of the two gate
leaves is done to avoid their incorrect overlapping.
TECHNICAL SPECIFICATIONS
- Temperature range 0 ÷ 55 °C
- Humidity < 95 % without condensation
- Voltage 230 V~ ± 10% (120 V 60 Hz upon request)
- Frequency 50/60 Hz
- Battery power 20-24 Vdc
- Transformer Power 130 VA - primary 230 Vac - secondary 18 Vac
- Maximum absorption 25 mA
- Power supply microinterruptions 100ms
- Maximum power SIGNAL output 24 Vdc 3 W (equivalent to one 3W or 5 LED light
bulb with resistor in series at 2.2 K ohm)
- Maximum blinker power 24 Vdc 20 W
- Power for photocells and accessories 1 A ± 15 %
- Power for radio connector 200 mA
RADIO SPECIFICATIONS (model B2 24V-CRX)
- Reception frequency 433,92 MHz
- Impedence 52 ohm
- Sensitivity >1 µV
- Feedback control PLL
- Memory storage (codes) 1000
- All inputs must be used as clean contacts because the power is generated internally (secure
power) to the board and is set up to ensure compliance with double or reinforced insulation
with regard to dangerous voltage.
- Any external circuits connected to the outputs of the control panel must be made in such
a manner as to ensure compliance with double or reinforced insulation with regard to
dangerous voltage.
- All inputs are controlled by a programmed integrated circuit that performs a self check
every time it starts operating.
