RIB B2 24V - SIGNALS DURING PROGRAMMING AND OPERATION

29
TABLE SUMMARISING VISUAL AND SOUND ALARMS
SIGNALS DURING PROGRAMMING SEQUENCE
EVENT BUZZER STATUS FLASHER STATUS DL1 LED STATUS
Dip 1 ON (hold-to-run mode)
Or failure of a safety device
Off Off Flashes on-off 250 ms
Dip 2 ON (full stroke programming) Off Off Flashes on-off 500 ms
Dip 2>1 ON (pedestrian stroke programming) Off Off Flashes on-off 500 ms
Programming sequence stopped due to intervention of a safety
device
10 seconds tone with 2 seconds pause Off On steady
EVENT BUZZER STATUS FLASHER STATUS DL12 LED STATUS
No transmitter code entered Off Off Flashes intermittently red/green
Dip 1 > 2 - transmitter code programming for full opening Off Off Flashes red for 10 seconds
Dip 1 > 3 - transmitter code programming for pedestrian
opening
Off Off Flashes green for 10 seconds
Dip 1>2> 3 - transmitter code programming for R-AUX relay Off Off Flashes orange for 10 seconds
Correct transmitter codes programming for full opening and
R-AUX relay
1 Tone Off Turns green once
Correct transmitter codes programming for pedestrian opening 1 Tone Off Turns red once
Remote control code not present in memory Off Off Red flash
Memory saturated by remote control codes (1000 codes saved) Off Off Runs 6 green flashes
Radio code deletion for full opening, pedestrian opening, R-AUX
relay
2 Tones Off Runs 2 green flashes
WARNING SIGNALS DURING OPERATION
EVENT BUZZER STATUS FLASHER STATUS LED STATUS AND SIGNAL OUTPUT
Stop button pressed Off Off Led DL6 turns off
Photocell intervention 1 Tone Off Led DL7-8 turns off
Edge intervention 2 Tones Off Led DL9-10 turns off
Intervention of impact sensor 3 Tones Off No led combined
Failure of a safety device or safety device engaged for too long Off Off Led DL1 flashes on-off 250 ms
Running with emergency batteries (24 vdc) Off Currently enabled Signal output flashes on-off twice for 250 ms
followed by a pause of 2 seconds
Emergency batteries low signal 1 Tone every 5 seconds for 1 minute
(It is renewed by giving a command)
Off Signal output flashes continuously on-off for 500
ms
Operation with emergency batteries charged by solar panels Off Off Signal output flashes on-off 3 times for 250 ms
followed by a pause of 2 seconds
Alarm from edge 2 Tones every 5 seconds for 1 minute
(It is renewed by giving a command)
Enabled for 1 minute No led combined
Impact sensor alarm 3 Tones every 5 seconds for 1 minute
(It is renewed by giving a command)
Enabled for 1 minute No led combined
Failed photocells auto-test alarm 4 Tones every 5 seconds for 1 minute
(It is renewed by giving a command)
Off No led combined
Functional block activated by smartphone Off Off Led DL12 is steady on green.
Achievement of set cycles 6 Tones every 5 seconds for 1 minute
(It is renewed by giving a command)
Off No leds matched
Energy saving activated by smartphone Off Off Blue led flashes once every 5 seconds
