FAULT SOLUTION
After having carried out the various connections and having supplied voltage, all the LEDS
are switched off.
On the board there are resettable fuses which intervene in the event of a short circuit,
interrupting the output assigned to them.
In the event of troubleshooting, it is advisable to disconnect all the removable
connectors and insert them one at a time in order to more easily identify the cause
of the fault.
Check the integrity of fuse F1. If the fuse is blown, use only a suitable replacement.
F1 = T 5A MOTOR PROTECTION FUSE
The motor opens and closes, but it has no strength and moves slowly. Check trimmers TORQUE and LOW-SPEED adjustment.
The gate opens but does not close after the time set.
Make sure that the TCA trimmer is activated with LED DL6 ON.
B.I.O. contact always on => check the status of the clock connected to B.I.O..
Photocells Auto-test failed => check the connections between the control panel and the
photocells.
The gate does not open or close by activating the various START, RADIO, OPEN and CLOSE
buttons.
Stop, Edge or Photocell with DIP 4 OFF contact fault => Fix or replace the faulty contact.
Photocells Auto-test failed => check the connections between the control panel and the
photocells.
The electric lock does not work.
Ensure to have enabled DIP 8 at ON.
Check the cable.
The buzzer emits 2 long tones and the gate does not move
Safety edge with 8,2 KΩ resistor. Remove the resistor or configure the EDGE input via the
RIB GATE app
The remote control does not work. Led DL12 lit red Lack of radio module in connector J5 or faulty radio module.
TABLE SUMMARISING VISUAL AND SOUND ALARMS
SIGNALS DURING PROGRAMMING SEQUENCE
EVENT BUZZER STATUS FLASHER STATUS DL1 LED STATUS
Dip 1 ON (hold-to-run mode)
Or failure of a safety device
Off Off Flashes on-off 250 ms
Dip 2 ON (full stroke programming) Off Off Flashes on-off 500 ms
Dip 2>1 ON (pedestrian stroke programming) Off Off Flashes on-off 500 ms
Programming sequence stopped due to intervention of a safety
device
10 seconds tone with 2 seconds pause Off On steady
EVENT BUZZER STATUS FLASHER STATUS DL12 LED STATUS
No transmitter code entered Off Off Flashes intermittently red/green
Dip 1 > 2 - transmitter code programming for full opening Off Off Flashes red for 10 seconds
Dip 1 > 3 - transmitter code programming for pedestrian
opening
Off Off Flashes green for 10 seconds
Dip 1>2> 3 - transmitter code programming for R-AUX relay Off Off Flashes orange for 10 seconds
Correct transmitter codes programming for full opening and
R-AUX relay
1 Tone Off Turns green once
Correct transmitter codes programming for pedestrian opening 1 Tone Off Turns red once
Remote control code not present in memory Off Off Red flash
Memory saturated by remote control codes (1000 codes saved) Off Off Runs 6 green flashes
Radio code deletion for full opening, pedestrian opening, R-AUX
relay
2 Tones Off Runs 2 green flashes
WARNING SIGNALS DURING OPERATION
EVENT BUZZER STATUS FLASHER STATUS LED STATUS AND SIGNAL OUTPUT
Stop button pressed Off Off Led DL6 turns off
Photocell intervention 1 Tone Off Led DL7-8 turns off
Edge intervention 2 Tones Off Led DL9-10 turns off
Failure of a safety device or safety device engaged for too long Off Off Led DL1 flashes on-off 250 ms
Running with emergency batteries (24 vdc) Off Currently enabled Signal output flashes on-off twice for 250 ms
followed by a pause of 2 seconds
Alarm from edge 2 Tones every 5 seconds for 1 minute
(It is renewed by giving a command)
Enabled for 1 minute No led combined
Failed photocells auto-test alarm 4 Tones every 5 seconds for 1 minute
(It is renewed by giving a command)
Off No led combined
Functional block activated by smartphone Off Off Led DL12 is steady on green.
Achievement of set cycles 6 Tones every 5 seconds
(It is renewed by giving a command)
Off No leds matched
Energy saving activated by smartphone Off Off Blue led flashes once every 5 seconds
