OPTIONALS - For the connections and the technical data of the fixtures follow the relevant handbooks.
EXPANDER CARD
!! FEED THE EXP CARD IN WHEN POWER IS NOT SUPPLIED !!
- PEDESTRIAN OPENING COMMAND
- AUTOMATIC PEDESTRIAN CLOSING
- MANAGEMENT OF THE SAFETY EDGE
- 24VAC ACCESSORIES FEEDING
- MANAGEMENT OF THE TRAFFIC LIGHT CONTR
- MANAGEMENT OF THE COURTESY LIGHT
- CLOSING COMMAND AFTER PASSING THROUGH THE
PHOTOCELLS* code ACG5470
D5
D4
D3
D2
BLOCK
KEY SELECTOR FOR WALL-INSTALLATION code ACG1053
KEY SELECTOR TO BUILD-IN code ACG1048
FIT SYNCRO
FIT SYNCRO PHOTOCELLS for the wall-installation code ACG8026
The range you can set is 10-20 m, 30÷60ft.
You can fit many couples close together thanks to the synchronising
circuit.
Add the SYNCRO TRANSMITTER code ACG8028
for more than 2 photocells couples (up to 4).
COUPLE OF BUILT-IN BOXES FOR THE FIT SYNCRO
code ACG8051
CODE LEARNIG SYSTEM RADIORECEIVERS
RX433/A super eterodyne and coupling code ACG5055
RX433/A super eterodyne and terminal board code ACG5056
RX433/A 2CH super eterodyne, 2 channel and coupling code ACG5051
RX433/A 2CH super eterodyne, 2 channel and terminal board
code ACG5052
SUN 2CH code ACG6052 SUN 4CH code ACG6054
SUN CLONE 2CH code ACG6056 SUN CLONE 4CH code ACG6058
RADIO TRANSMITTER SUN
SPARK
In order to make the systems mentioned above give the best
performances, you need to install an antenna tuned on the frequency
of the radio receiver installed.
N.B. Pay attention to not let the central wire of the cable to came
Into contact with the external copper sheath, since this would
prevent the antenna from working.
Install the antenna vertically and in such a way the remote control can
reach it.
SPARK BLINKER WITH IN-BUILT INTERMITTENT CARD
code ACG7059
LATERAL SUPPORT code ACG7042
SPARK ANTENNA 433 code ACG5452
