9.2 Banknote jamming and solution
If the notes get jammed during counting progress, there will be warning
messages displayed on the screen. You need to take out the jammed notes
firstly and then press START key to check if there is still hidden jammed notes.
Last, press CLEAR key to clear warning message. If the machine still displays
“JAM”, you will need to open the machine and take out the notes from interior
passage.
Once jamming happens, please recount the notes to avoid counting
mistake.
*After clean the sensor and passagewell, please press “ ” key to
clear the error interface and enter into main interface to go on counting.
*If after checking, there is no foreign items blocking the sensor, and after
press “ ” key there is still error interface, please refer to service manual
to do trouble shooting.
10. Software Upgrade
This model adopts flash drive (USB) upgrading method for software upgrade.
Please copy the upgrading file into the flash drive, and insert the flash drive into
the USB port at the back of machine. Hold on pressing the START key, and then
turn on the power switch, you will find the choosing interface as follows:
Fig.53 Fig.54
*If the USB flash drive is inserted well, the display will show “USB is Ready!”,
otherwise it will show “Please insert the U-Disk!”.
For the upgrading file, it is not allowed to change its name and format,
otherwise will cause upgrade failure.
