Ribao BCS-160 - 4 Specification

BCS-160User Manual V1.6
9
/
57
4. Specification
Dimension(W×L×H)
340mm×340mm×380mm
Weight
13KG
Hopper Capacity
600pcs
Stacker
200pcs
Reject Pocket Capacity
100pcs(brand new)
Display
3.5 inch TFT Screen
Interface
RS-232/LAN/RJ12/SD/USB
Currency Support
Maximum 14 currencies
Sortable Notes Size
Width: 100mm~180mm
Length: 50mm ~90mm
Sortable Notes Thickness
0.05mm~0.12mm
Counting Speed
800/1000pcs/min (MIX/SDC mode)
800/1000/1200pcs/min (CNT modes)
Sorting Modes
MIX Counting Mode, FACE Sorting Mode,
Denomination Sorting Mode, Orientation Sorting
Mode, Pieces Counting Mode
Batch No.
0~200
Counterfeit Detection
UV/MG/MT/IR
Power Supply
AC 220V 50Hz ±10%
AC 110V 60Hz ±10%
Power Consumption
Sleeping Mode ≤15W
During Operation ≤70W
Working Condition
Temperature(0~40°C)/Humidity(40~90%)
Air Pressure(70-106kpa)
Storing Condition
Temperature(-40~55°C)/Humidity(10~95%)
Air Pressure(70-106kpa)
