Eg2.: If the lathe working feed count is divide
0.5, the “LastPcnt” value is 0.1, then two times in the mi
by the dsp system
(the two times feed depth ratio in the middle are both 0.2).
“FrstPcnt”
and “LastPcnt” lose efficacy when the “Feed cnt” value is 1.
3. Spiral work list
(1) ScrewCnt(TwistCnt)
Twist number in need
for processing
(2) ScrewAgl
The rotating angle of a twist in processing
line.
(3) ScrewPls(RotaPuls)
Pulse equivalent of a rotating shaft
(4) ScrewSpd(RotaSpd)
The speed of
rotating shaft
(5) ScrewCnt
How many processing times for completing one twist (The depth of each process will
be evenly distributed).
(6) 1 WayScrw
One-
way screw processing can avoid screw gap, it twisting from only one side to
another every time.
4. Loop Proc Setup
Set recycle the processing files. First, select lathe grinding file (The first letter of the
file name must be D)
, and then choose spiral file
letter of the S) .
5. Work speed
Work speed in “4 axis” mode.
6.
Lathe work speed
Wor
k speed in lathe turning & grinding mode.
7. Origin offset
Workpiece zero offset, each axis position offset in the setting of the working origin.
8. Auto speed ratio
In auto processing, a
ctual processing speed=work speed*auto s
speed ratio” does
not affect the “fast speed”.
9. Fall down scale
Fall down scale，
system default is 1.000
fall down speed = Z-
(neg)
