Operation Panel Display
 Examine the table below. This shows the LED
flash combinations that appear on the operation
panel when an error occurs.
8. Troubleshooting
Error LED Status
Open fusing unit error
The [Error] LED (red) and the [Toner Save] LED flash simultaneously at 1
second intervals.
Overheat error
The [Error] LED (orange) and the [Toner Save] LED flash simultaneously
at 1 second intervals.
Low heat error
The [Error] LED (red) and the [Toner Save] LED flash simultaneously at 4
second intervals.
LSU not ready error (polygon
motor error)
The [Error] LED (green) and the [Toner Save] LED flash simultaneously at
1 second intervals.
LSU not ready error (HSYNC
error)
The machine stops printing and the [Error] LED (green) and the [Toner
Save] LED flash simultaneously at 4 second intervals.
