SYStem SpecificationS
Ricoh Aficio MP 301SPF
R3348
Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006, 1-800-63-RICOH
Ricoh
®
and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. All other trademarks are the property of their respective owners. The content of this document, and the
appearance, features and specifications of Ricoh products and services are subject to change from time to time without notice. Products are shown with optional features. While care
has been taken to ensure the accuracy of this information, Ricoh makes no representation or warranties about the accuracy, completeness or adequacy of the information contained
herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services, and the conditions and factors
affecting performance. The only warranties for Ricoh products and services are as set forth in the express warranty statements accompanying them.
General Specifications
Configuration Desktop Multifunctional Product (MFP)
Scanning Element Flatbed with CCD array image-sensing
element
Printing Process Laser beam scanning/marking & electro-
photographic printing
System Memory 1GB. (RAM) standard
Output Speed Up to 31 ppm (Letter)
(Copy/Print)
First Copy Time 6 seconds or less
Recovery Time to Less than 23 seconds (from main power
Product Ready Mode switch on)
Less than 10 seconds (from sleep mode)
Copy Resolution 600 x 600 dpi (platen), 600 x 300 (ARDF)
Grayscale 256 levels
Exposure Adjustment Manual and automatic
Multiple Copies Up to 99
Document Feeder Automatic Reversing Document Feeder
(Standard) (ARDF)
Original Capacity 50 sheets (ARDF)
Paper Sizes Standard Tray: 5.5" x 8.5" to 8.5" x 11"
(A4/ LT/A5/HLT)
Optional Trays: 8.5" x 11" to 8.5" x 14"
(A4/LT/ LG/Folio)
Bypass Tray: 5.5" x 8.5" to 8.5" x 14"
(A6/A5/A4/LT/LG)
Duplex Unit: 8.5" x 11" to 8.5" x 14"
(A4/LT/LG)
Paper Weights Standard/Optional Trays: 16 – 24 lb. Bond
(60 – 90 g/m
2
)
Bypass Tray: 16 – 42 lb. Bond (60 – 157 g/m
2
)
Duplex Unit: 20 – 24 lb. Bond (60 – 90 g/m
2
)
Exposure Glass Up to 8.5" x 14"
Input Capacity Standard: 250 sheets + 100-Sheet
Bypass Tray
Optional: 500 sheets x 1 or 2 Trays
Output Capacity 250 sheets (internal tray)
Paper Types Plain, Recycled, Colored, Letterhead,
Preprinted, Bond, Card Stock, Prepunched,
Special, Thick*, OHP (Transparency)*
Envelopes*, Label Stock*
Auto Duplex Standard
Zoom 25% to 400% in 1% increments
Preset Reduction and 65%, 78%, 93%, 129%, 155%
Enlargement Ratios
Dimensions (WxDxH) 19.0" x 17.7" x 18.1" (476 mm x 450 mm
x 451 mm) – includes ARDF
Weight 57.3 lbs./ 26 kg.
Power Requirements 120V, 60Hz, 8A
Power Consumption Less than 1,1 kW (max.)
Sleep Mode, 2.8 W (MP 301SPF)
TEC MP 301SPF – 1.507 kWh/week***
Standard Features Document Server**, Image Rotation, Auto
Off Timer, Combine Copy, Electronic Sort,
Energy Saver Timer, Photo Mode, Series
Copy, Job Programs (25), User Codes
(8 digits, 1,000 Personal Codes)
*Bypass Tray only.
**HDD option required.
***Typical electric consumption by ENERGY STAR program
Printer
CPU RM7035C – 533 MHz
Memory Capacity Standard: 1 GB RAM
Hard Disk Drive Optional: 128 GB HDD
Page Description Standard: PCL5e/6, Genuine Adobe
®
Languages PostScript
®
3
Maximum Print Resolution 600 x 600 dpi
Standard Interfaces Ethernet (RJ-45 network port : 10Base-T/
100Base-TX), USB2.0 Type A and B
Optional Interfaces IEEE1284, Wireless LAN (IEEE802.11a/b/g),
Giga Ethernet (1000BASE-T), Bluetooth
Network Protocols TCP/IP (IPv4, IPv6), IPX/SPX (available
with Netware option)
Fonts for PCL 5e/6 45 Roman fonts
Fonts for PS3 136 Roman fonts
Network Operating Windows XP/Server 2003/Vista/Server
Systems 2008/7; Novell Netware 6.5; UNIX Filters
for Sun Solaris 2.6/7/8/9/10; HP-UX
10.x/11.x/11iv2/11iv3; Red Hat Linux
Enterprise V4, V5, V6; SCO OpenServer
5.0.6/5.0.7/6.0; IBM AIX Version 5.3,
6.1, 7.1; SAP R/3, 3.x or later, mySAP,
ERP2004 or later; Mac OSX 10.2 or later,
Citrix Metaframe XP/ Presentation Server
4, 5/XenApp 5.0, 6.0
Utilities SmartDeviceMonitor for Admin and Client,
Web SmartDeviceMonitor, Web Image Monitor
Other Printer Features Media Direct Print (Print from USB/SD)
1
,
Mobile Driver, Bonjour Support,
Classification Code, Mail to Print
1
, PDF
Direct Print, Sample/Hold/Stored/Locked
Print
1
, Store and Print
1
, Windows Active
Directory Support, DDNS Support,
WSPrinter, PCL resident font adoption,
Tray-Parameter Change from
WebImageMonitor, XPS Support
1
HDD option required.
Scanner
Scanning Speed 31 ipm @ 300 dpi B/W (LT)
21 ipm @ 300 dpi Full-Color (LT)
Scanning Resolution 100 to 600 dpi
Scan Area Main: 8.5" (216 mm)
Sub: 14.02" (356 mm)
Compression Method B/W: MH (default), MR, MMR, JBIG2
Full-Color: JPEG
Scan Mode B/W: Text, Text/Line Art, Text/Photo,
Photo, Grayscale
Full-Color: Text/Photo, Glossy Photo,
Grayscale
Standard Interfaces Ethernet 10BASE-T/100BASE-TX
Optional Interfaces Wireless LAN (IEEE 802.11a/b/g), Gigabit
Ethernet (1000BASE-T)
File Formats: Single/Multi Page TIFF,
Single/Multi Page PDF, Single/Multi Page
High Compression PDF and Single/Multi
Page PDF/A; Single Page JPEG
Scan Modes Supported Scan-to-USB/SD, Scan-to-Email (POP,
SMTP, TCP/IP)
1
; Scan-to-Folder (SMB/
FTP/NCP)
2
; Network TWAIN Scanning;
WSDScanner for Vista
Standard Features PDF Encryption, Preview Before
Transmission (TX Preview)
1
, Drop Out Color
Send, Simultaneous Fax and Scan,
Scan-to-Email/SMB/FTP/URL
1
/NCP
2
,
LDAP Support, TWAIN Scanning
1
HDD option required.
2
Netware option required
Fax
Type ITU-T (CCITT) G3
Circuit PSTN, PBX
Resolution 200 x 100 dpi, 200 x 200 dpi
Modem Speed 33.6K – 2,400 bps with Auto Fallback
Compression Method MH, MR, MMR, JBIG
Scan Speed 2.4 seconds (Letter)
Transmission Speed Approx. 2 seconds/page (JBIG)
Memory 4 MB (approx. 320 pages)
Memory Backup 12 hours
Quick/Speed Dials 200 (2,000 with HDD Option)
Group Dials 10 groups (max. 100 numbers per group
with HDD option)
User Function Key 3 keys
Standard Features Detection of Misplaced Documents,
Double Check Destination Address, Direct
SMTP, Simultaneous Fax and Scan, Fax
Forward to Email/Folder, Internet Fax
(T.37)
1
, IP Fax (T.38)
1
, LAN Fax, Paperless
Fax
1
, LDAP Support
1
HDD option required.
Paper Feed Unit PB1040 (Option)
Paper Size 8.5" x 11" SEF, 8.5" x 14" SEF (A4/LT/LG)
Paper Weight 16 – 24 lb. Bond (60 – 90 g/m
2
)
Paper Capacity 500 sheets x 1 or 2 Trays
Additional Options
HDD Option Type 301 (includes HDD overwrite and encryption),
Cabinet, Type FAC57, Cabinet, Type FAC58, IEEE1284 Interface
Board Type A, IEEE802.11a/g Interface Unit Type J, Gigabit Ethernet
Board Type A, Bluetooth Interface Unit Type D, VM Card Type U, File
Format Converter Type E, Browser Unit Type G, SD Card for NetWare
Printing Type I, Unicode Font Package for SAP (1/10/100 License
Packs available), Handset Type C5502, Optional Counter Interface
Unit Type A, Copy Data Security Unit Type F, ACK3400-U Key Board
Security
Quota Setting/Account Limit; SMTP over SSL; Hard Disk Data
Overwrite Security
1
; Authentication (Windows/LDAP/Kerberos/Basic/
User Code/802.1.x Wired); Encryption (Address Book/Authentication
Password/SSL Communication/S/MIME/IPsec/Locked Print
Password/HDD
1
); Network Protocol (Port) On/Off; IP Filtering; Copy
Data Security Unit; RAM Based Security when HDD is not installed
1
Only required with HDD option.
Some features may require additional options.
www.ricoh-usa.com
MP 301SPF and FAC 57
Cabinet
MP 301SPF with Optional PB1040
Paper Tray and FAC 58 Cabinet
MP 301SPF with Two Optional PB1040
Paper Trays and FAC 58 Cabinet
