SYSTEM SPECIFICATIONS
Ricoh Aficio MP 6002/MP 7502/MP 9002
R3374-1
Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355, 1-800-63-RICOH
Ricoh
®
and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. All other trademarks are the property of their respective owners. ©2012 Ricoh Americas Corporation. All rights
reserved. The content of this document, and the appearance, features and specifications of Ricoh products and services are subject to change from time to time without notice. Products
are shown with optional features. While care has been taken to ensure the accuracy of this information, Ricoh makes no representation or warranties about the accuracy, completeness or
adequacy of the information contained herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services,
and the conditions and factors affecting performance. The only warranties for Ricoh products and services are as set forth in the express warranty statements accompanying them.
Specifications
Memory (RAM) 1.5 GB
HDD 250 GB
First Copy Time MP 6002: 3.9 seconds
MP 7502: 3.2 seconds
MP 9002: 2.9 seconds
Recovery Time to MP 6002/MP 7502: 30 seconds
Print Ready Mode MP 9002: 300 seconds
Copy Speed 60/75/90 copies/minute multiple sets
(Letter LEF)
Original Size Up to 11" x 17"
Copy Size 5.5" x 8.5" – 11" x 17"
Copy Resolution True 600 x 600 dpi
Grayscale 256 levels
Zoom 25% – 400% in 1% increments
Paper Capacity Standard: Tray 1: 1,550 sheets x 2
(tandem) = 3,100 (Letter); Trays 2 & 3:
550 sheets each (user adjustable)
Bypass: 100 sheets
Total Standard/Max: 4,300/8,300 sheets
Paper Weight Trays 1 – 2: 52 – 169 g/m
2
(14 lb. Bond –
45 lb. Bond)
Tray 3: 52 – 216 g/m
2
(14 lb. Bond –
80 lb. Cover)
Power Requirements 120V/60Hz/20A (Requires dedicated
20A outlet)
MP 9002: 208-220V/60Hz/20A
(Requires dedicated 20A outlet)
Typical Electricity MP 6002: SP version: 6.02 kWh
Consumption (TEC) MP 7502: SP version: 6.83 kWh
MP 9002: SP version: 14.07 kWh
Dimensions (WxDxH) 27.2" x 31.5" x 46.1" (690 x 799 x
1171 mm)
Weight 471.6 lbs. (214 kg)
System Accessories
Automatic Document Feeder (Standard)
Original Size 5.5" x 8.5" – 11" x 17"
Paper Weight
Simplex: 11 lb. – 34 lb. Bond (40
–
128 g/m
2
)
Duplex: 14 lb. – 34 lb. Bond (40
–
128 g/m
2
)
Capacity
150 sheets (based on 20 lb. Bond – 75 g/m
2
)
Options
RT4010 Large-Capacity Tray (LCT)
Paper Size 8.5" x 11"/A4 (LEF)
Paper Weight 14 – 34 lb. Bond (52 – 128
g/m
2
)
Paper Capacity 4,000 sheets (20 lb. Bond – 75 g/m
2
)
Dimensions (WxDxH) 12.36" x 18.03" x 25.94" (314 x 458 x
659 mm)
8.5" x 14" Paper Size Tray Type 9002
Enables legal-size (8.5" x 14") paper to be fed through LCT.
Paper Size 8.5" x 14"/B4, 8.5" x 11" /A4 SEF
Paper Capacity 2,500 sheets (20 lb. Bond – 75 g/m
2
)
CS4000 9-Bin Mailbox
Compatible with SR4060 and SR4070 Finishers.
Number of Bins 9
Stack Capacity 100 sheets/bin (20 lb. Bond – 75 g/m
2
)
Paper Size 5.5" x 8.5" – 11" x 17"
Copy Tray Type 9002
Paper Capacity 500 sheets (8.5" x 11", 8.5" x 15"),
250 sheets (5.5" x 8.5", 11" x 17")
11" x 17" Tray Type 9001
Enables 8.5" x 11" – 11" x 17" paper to be fed from Tray 1.
Paper Size 11" x 17" SEF, 8.5" x 14" SEF, 8.5" x 11"
Paper Capacity 1,000 sheets
Cover Interposer Tray Type CI4000
Compatible with all three finishers.
Paper Size 5.5" x 8.5" – 11" x 17"
Paper Weight 17 lb. Bond – 110 lb. Index (64 – 216 g/m
2
)
Paper Capacity 200 sheets (20 lb. Bond – 75 g/m
2
)
FD4000 Multi-Folding Unit
Compatible with SR4080 and SR4070 only.
Folding Type
Single Sheet Mode Z-Fold, Half-Fold, Letter Fold-in, Letter
Fold-out, Double Parallel, Gate-Fold
Multiple Sheets Mode Half-Fold, Letter Fold-in, Letter Fold-out.
Up to 3 sheets
Paper Size
Single Sheet Mode Z-Folding: 8.5" x 11" – 11" x 17"
Half-Folding: 8.5" x 11" – 11" x 17"
Letter Folding: 8.5" x 11" – 11" x 17"
Double Parallel/Gate-Folding: 8.5" x 11"
Multiple Sheets Mode Half-Folding: 8.5" x 11" – 11" x 17"
Letter Folding: 8.5" x 11"
SR4070 2,000-Sheet Saddle-Stitch Finisher with 50-Sheet
Stapler
Proof Tray
Paper Size 5.5" x 8.5" – 11" x 17" (A5-A3) SEF
Paper Weight 14 lb. Bond – 90 lb. Index (52 – 128 g/m
2
)
Stack Capacity 250 sheets (8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
30 sheets (Z-Fold/8.5" x 14" or larger)
20 sheets (Z-Fold/8.5" x 11" or smaller)
Shift Tray
Paper Size 5.5" x 8.5" – 11" x 17" (SEF)
Paper Weight 14 lb. Bond – 80lb. Cover (52 – 216 g/m
2
)
Stack Capacity 2,000 sheets (8.5" x 11" LEF)
1,000 sheets (8.5" x 11" SEF,
8.5" x 14" SEF, 11" x 17" SEF)
100 sheets (5.5" x 8.5" SEF)
30 sheets (Z-Fold/8.5" x 14" or larger)
20 sheets (Z-Fold/8.5" x 11" or smaller)
Staple Capacity
Same Paper Size 50 sheets (8.5" x 11" or smaller)
30 sheets (8.5" x 14" or larger)
Mixed Paper Size 30 sheets (8.5" x 11", 11" x 17")
Z-Fold Paper Only 5 sheets
Saddle-Stitch 15 sheets (8.5" x 11" SEF, 8.5" x 14" SEF,
11" x 17" SEF)
Staple Position Top, Bottom, 2 Staples, Top Slant Booklet
Dimensions (WxDxH) 25.9" x 24.1" x 37.8" (657 x 613 x 960mm)
Punch Unit Type 3260 (For use on SR4060/4070 nishers)
Hole Positions 2 or 3 holes
Paper Size 5.5" x 8.5" – 11" x 17"
Paper Weight 14 lb. Bond – 90 lb. Index (52 – 163 g/m
2
)
SR4080 3,000-Sheet Finisher with 100-Sheet Stapler
Proof Tray
Paper Size 5.5" x 8.5" – 11" x 17" (A5-A3) SEF
Paper Weight 14 lb. Bond – 80 lb. Cover (52 – 216 g/m
2
)
Stack Capacity 500 sheets (8.5" x 11" or smaller)
250 sheets (8.5" x 14" or larger)
30 sheets (Z-Fold)
Shift Tray
Paper Size 5.5" x 8.5" – 11" x 17" (A5-A3) SEF
Paper Weight 14 lb. Bond – 110 lb. Index (52 – 216 g/m
2
)
Stack Capacity 3,000 sheets (8.5" x 11" LEF)
1,500 sheets (8.5" x 11" SEF,
8.5" x 14" SEF, 11" x 17" SEF)
500 sheets (5.5" x 8.5" LEF)
100 sheets (5.5" x 8.5" SEF)
30 sheets (Z-Fold)
Staple Capacity
Same Paper Size 100 sheets (8.5" x 11")
50 sheets (8.5" x 14", 11" x 17")
Mixed Paper Size 50 sheets (8.5" x 11" LEF, 11" x 17" SEF)
Z-Fold Paper Only 10 sheets
Staple Positions Top, Top Slant, Bottom, 2 Staples
Dimensions (WxDxH) 31.5" x 28.7" x 38.6" (800 x 730 x 980mm)
Punch Unit Type 1075
Hole Positions 2 or 3 holes
Paper Size 5.5" x 8.5" – 11" x 17"
Paper Weight 14 lb. Bond – 90 lb.Index (52 – 162 g/m
2
)
SR4060 3,000-Sheet Finisher with 50-Sheet Stapler
Proof Tray
Paper Size 5.5" x 8.5" – 11" x 17" SEF
Paper Weight 14 lb. Bond – 90 lb. Index (52-163 g/m
2
)
Stack Capacity 250 sheets (8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Shift Tray
Paper Size 5.5" x 8.5" – 11" x 17" SEF
Paper Weight 14 lb. Bond – 80 lb. Cover (52 – 216 g/m
2
)
Stack Capacity 3,000 sheets (8.5" x 11" LEF)
1,500 sheets (8.5" x 11" SEF,
8.5" x 14" SEF, 11" x 17" SEF)
100 sheets (5.5" x 8.5" SEF)
Staple Capacity
Same Paper Size 50 sheets (8.5" x 11" or smaller)
30 sheets (8.5" x 14" or larger)
Mixed Paper Size 30 sheets (8.5" x 11" LEF, 11" x 17" SEF)
Staple Positions Top, Bottom, 2 Staples, Top Slant
Dimensions (WxDxH) 25.9" x 24.1" x 37.8" (657 x 613 x 960mm)
GBC StreamPunch PRO
Paper Size 8.5" x 11" LEF
Paper Weight 20 lb. Bond – 110 lb. Index (75 – 216 g/m
2
)
Die Sets CombBind
®
, Twin Loop Wire (2:1 or 3:1),
ColorCoil
®
, VeloBind
®
, Three-Ring, ProClick
®
BK5010e Production Booklet Maker
Paper Size 8.5" x 11" – 11" x 17"
Paper Weight 16 lb. Bond – 110 lb. Index (60 – 216 g/m
2
)
Print Controller Specifications
Print Speed MP 6002: 60 ppm
MP 7502: 75 ppm
MP 9002: 90 ppm
CPU Intel Celeron M 1.0 GHz
Host Interface Standard: 10Base-T Ethernet/100Base-TX
Ethernet, USB 2.0, SD Card Interface
Optional: IEEE 1284 (Parallel), IEEE
802.11a/b/g (Wireless LAN), Gigabit
Ethernet
Network Protocol TCP/IP (IPv4/IPv6), IPX/SPX
1
1
Requires Netware Option
Memory Capacity 1.5 GB
PDL Standard: PCL5e, PCL6
Optional: Adobe PostScript 3
©
Print Resolution PCL5e: 300/600 dpi
PCL6: 600/1200 dpi
PS 3: 300/600/1200 dpi
Drivers PCL5e/PCL6 /PS3
Scanner Specifications
Scan Speed B/W 200 dpi (LT): 88 ipm (Simplex)/
176 ipm (Duplex)
B/W 300 dpi (LT): 88 ipm (Simplex)/
176 ipm (Duplex)
Color 200 dpi (LT): 88 ipm (Simplex)/
176 ipm (Duplex)
Color 300 dpi (LT): 88 ipm (Simplex)/
120 ipm (Duplex)
Optical Resolution 100 dpi – 600 dpi (100 – 1200 dpi
with TWAIN)
Output Format Single Page: TIFF/JPEG, PDF, High
Compression PDF, Encrypt PDF, PDF/A
Multi Page: TIFF, PDF, High Compression
PDF, Encrypt PDF, PDF/A
Interface Support Standard: 10Base-T Ethernet/
100Base-TX Ethernet;
Optional: IEEE 802.11a/b/g, Gigabit Ethernet
Drivers Network TWAIN Driver and WIA Driver
1
Scan-to-Email Yes (up to 500 addresses per send)
LDAP Support Yes (Version 3)
Max Stored Destinations 2,000
Authentication SMTP/POP before SMTP
Scan-to-Folder Yes (up to 50 folders per job)
Protocol Support SMB, FTP, NCP (requires netware option)
Scan-to-Media USB/SD Card
1
Download driver from website.
Facsimile Specifications (Optional)
Type ITU-T (CCIT) G3, Additional G3 (Optional)
Circuit PSTN, PBX
Resolution 200 x 100 dpi (Standard Mode); 200 x
200 dpi (Detail Mode); 200 x 400 dpi (Fine
Mode); 400 x 400 dpi (Super Fine Mode;
available with optional SAF memory)
Modem Speed 33.6 Kbps with auto fallback
Compression Method MH, MR, MMR, JBIG
G3 Transmission Speed Approximately 2 seconds/page (with JBIG);
Approximately 3 seconds/page (with MMR)
Scan Speed 0.70 seconds/page (Standard/Detail/Super
Fine Mode; LTR SEF)
Auto Dialing 2,000 Quick Dials, 100 Group Dials (500
locations each)
SAF Memory Capacity Standard: 4 MB (Approximately 320 pages);
Maximum: 28 MB (approximately 2,240
pages) with memory option
Additional Modes Internet Fax by e-mail (T.37), IP Fax (T.38),
LAN Fax, Fax Forward to E-mail/Folder,
LDAP support
Options G3 Interface Unit Type 9002 (provides one
additional G3 line; up to two lines may be
added for a maximum of three lines); Memory
Unit Type B (32 MB for fax option), Fax
Connection Unit Type E
Accessories
Gigabit Ethernet Type B, IEEE802.11a/g Interface Unit Type J,
PostScript3 Unit Type 9002, SD Card for NetWare Printing Type L,
Browser Unit Type J, Fax Connection Unit Type E, File Format Converter
Type E, 32MB Memory Unit Type B, Copy Data Security Unit Type F
For maximum performance and yield, we recommend using genuine Ricoh parts
and supplies
www.ricoh-usa.com
