Display Panel
The display panel shows machine status, error messages, and function menus.
Don't apply strong impact or force to the screen. Or it may be damaged. Maximum force allowable
is approx. 30N (approx. 3 kgf). (N = Newton, kgf = Kilogram force. 1 kgf = 9.8N.)
The function items displayed serve as selector keys. You can select or specify an item by lightly pressing
them.
When you select or specify an item on the display panel, it is highlighted like . Keys appearing as
cannot be used.
The copy display is set as the default screen when the machine is turned on.
The display panels shown in this manual's illustrations are taken from a machine on which all options
are installed.
Simplified Display
This section explains how to switch to the simplified display.
When you press the [Simplified Display] key, the screen changes from the initial display to the simplified
display.
Letters and keys are displayed at a larger size, making operations easier.
Display Panel
71
2
