31
Carefully pull out the print cartridge
horizontally, holding itscenter.
• Do not shake the removed print cartridge.
Doing so can cause remaining toner to
leak.
• Place the print cartridge on paper or simi-
lar material to avoid dirtying your work-
space.
Lifting the guide plate, remove the
jammed paper carefully.
Slide the print cartridge in
horizontally. When the cartridge can
go no further, raise it slightly and
push it fully in. Then push down
on the cartridge until it clicks into
place.
Using both hands, carefully push up the front cover until it
closes.
• If paper is jammed in tray 2 but is difficult to locate, pull out tray 2 to remove it. After removing
the paper, carefully push tray 2 all the way back inside the machine.
• When closing the front cover, push the upper area of the cover firmly. After closing the cover,
check that the error is cleared.
BSP036S
BSP121S
BSP039S
To Next Page
