Ricoh Aficio SP 3510SF - Page 368

1. Pull tray 1 halfway out, and check for jammed paper. If there is jammed paper, remove it
carefully.
CMF067
2. Carefully slide tray 1 back in until it stops.
3. If paper is loaded in the bypass tray, remove the paper.
4. Close the bypass tray.
5. Push the side button to open the front cover, and then carefully lower it.
CMF068
6. Carefully pull out the print cartridge horizontally, holding its center.
CMF069
• Do not shake the removed print cartridge. Doing so can cause remaining toner to leak.
• Place the print cartridge on paper or similar material to avoid dirtying your workspace.
9. Troubleshooting
366
