Ricoh Aficio SP 3510SF - Page 380

8. Put the paper feed roller back in with the roller part facing downwards.
CMF117
9. Lower the lever to lock the paper feed roller.
CMF089
10. Close the ARDF cover.
CMF090
11. Lift the ARDF, and if there is original remaining in the ARDF, gently pull the jammed
original to remove it.
Be careful not to hold the input tray when lifting the ARDF, for the tray might be damaged.
9. Troubleshooting
378
