2. Unplug the power cord from the wall outlet. Remove all the cables from the machine.
3. Pull out tray 1 carefully with both hands.
CMF077
Place the tray on a flat surface. If there is paper in the tray, remove it.
4. Wipe the friction pads with a damp cloth.
CMC084
5. Wipe the rubber part of the roller with a soft damp cloth. After that, wipe it with a dry
cloth to remove the moisture.
CMF092
