Ricoh C9100 - Guide to Functions of the Attention Light

1. Attention light
See page 13 "Guide to Functions of the Attention Light".
Rear and right view
1
1
1
DET004
2
1
1
1. Vents
Prevent overheating.
2. Earth leakage breaker
Protects users from electric shock. For details about checking the earth leakage breaker, see "Checking the
Earth Leakage Breakers", Maintenance and Specifications.
Guide to Functions of the Attention Light
• Do not push or pull the attention light when installed to the machine. Doing so may result in
damage or malfunction of the attention light or the machine.
Guide to Names and Functions of Components
13
