If you are using the camera for the first time, read this section.
Rear View
1
1615 17
87
9
10
11
12
13
14
2
2
34 5
6
Item Name Refer to
1 Picture Display P.19
2 Strap Eyelet P.14
3 Terminal Cover
P.107, 114, 128, 131
4 Speaker P.74
5 Common Terminal for USB Port/AV Output
P.107, 114, 128, 131
6 HDMI Micro Output Terminal (Type D) P.107
7
N ( Macro)
P.34
8 ADJ./OK Button P.52
9
F ( Flash)
P.35
10
6 ( Playback) Button
P.39
11 MENU Button P.62, 65, 69, 78, 93, 109
12 Fn (Function) Button P.55
13
t ( Self-timer)/D ( Delete) Button
P.37, 42
14 DISP. Button P.41, 45, 48
15 Power (DC input) Cable Cover —
16 Battery/Card Cover P.27
17 Tripod Screw Hole P.146
