Ricoh D296 - Paper Path

Machine Overview
17
Paper Path
Callout Item Callout Item
[A] ADF transport path [E] Optional paper feed unit path (1st)
[B] 1-Bin tray path [F] Optional paper feed unit path (2nd)
[C] Duplex paper transport path [G] Standard paper tray path
[D] Bypass paper feed path
