Fusing
278
2. Push the hooks and remove the fusing thermistor [A]. ( × 1).
Fusing Pressure Roller Thermistors
1. Remove the fusing upper cover (Fusing Upper Cover)
2. Raise the fusing lever.
3. Remove the bracket [A]. ( × 4)
