A157/A159/A160 EM 100K 200K 300K NOTE
SORTER ADAPTER (A568)
Exit Drive Roller C Alcohol or Water
Upper Roller C Alcohol or Water
EM 120K 240K 360K NOTE
PAPER TRAY UNIT (A549/A550)
Pick-up, Feed, Separation
Rollers
C C R C Water, Replace these rollers
as a set.
Relay rollers C C C Alcohol or water
Bottom Plate Pad C R R R Water
Relay Clutch I I I Replace every 1500K copies.
Feed Clutch I I I Replace if necessary
Drive Belts I I I Replace if necessary
EM 80K 160K 240K NOTE
AUTO DOCUMENT FEEDER (A548) (for originals)
Transport Belt C R R R Belt cleaner
Friction Belt C R R R Water
Feed Roller C R R R Water
EM PM NOTE
20-BIN SORTER STAPLER (A554)
Transport and Exit Rollers C C Alcohol or water
Bins C C Alcohol or water
Bin and Paper Sensors C C Blower brush
Bushings L L Launa oil; if bushings generate
noise.
Worm Gears L L Grease G501; if worm gears
generate noise.
Bin Cam Tracks L L Grease G501; if bin cam tracks
generate noise.
10-BIN SORTER STAPLER (A555)
Transport Roller C C Alcohol or water
Bins C C Alcohol or water
Bin and Paper Sensors C C Blower brush
Bushings L L Launa oil; if bushings generate noise.
Helicam Wheels L L Grease G501; if helicam wheels
generate noise.
SORTER (A556/A557)
Bin Guide/Wheel L L Grease G501; if those generate
noise.
Bushings L L Grease G501; if bushings generate
noise.
Exit Roller C C Alcohol or water
FT5535/4527/4522 4-58 FSM
