Ricoh FT5535 - Page 207

3.13 TONER SCATTERING
- Problem -
Toner scatters from the development unit.
- Possible Causes -
1. The toner density is too high.
2. The inlet seal on the development unit is out of position.
3. The developer has deteriorated.
- Action -
Is the toner density too high?
No Yes
See section 1.11 "Toner Density Too High".
Is the inlet seal deformed?
No Yes
Replace the inlet seal plate.
Replace the developer.
FT5535/4527/4522 6-20 FSM
