5.2 A153/A156
1. Upper Paper Feed Clutch Gear (A153/A155 only)
2. Lower Paper Feed Clutch Gear
3. Relay Clutch Gear
5.3 A157/A160/A161/A162
1. Upper Paper Feed Clutch Gear (A157and A161 only)
2. Lower Paper Feed Clutch Gear
3. Relay Clutch Gear
Rev. 7/95
1
3
2
1
3
2
FT5535/4527/4522 2-14 FSM
