Component
(Symbol)
CN Condition Symptom
(When the main switch is turned on.)
Original Length-1
(S27)
118-3 Open
The CPU cannot detect the original size
properly. APS and ARE do not function
correctly.
Shorted
Duplex Paper End
[Duplex machines
only] (S28)
486-5 Open
"Copies Left In The Duplex Tray" is
displayed or the Paper Jam Z indicator
lights even if there is no paper in the
duplex tray.
Shorted
Only one rear side copy is made
regardless of the quantity of copies.
Duplex Turn
[Duplex machines
only] (S29)
140-9 Open
The machine indicates that originals
should be reset.
Shorted
"Copies Left In The Duplex Tray" is
displayed or the Paper Jam Z indicator
lights even if there is no paper in the
duplex tray.
Duplex Entrance
[Duplex machines
only] (S30)
*Misfeed detect
140-10 Open
"Copies Left In The Duplex Tray" is
displayed or the Paper Jam Z indicator
lights even if there is no paper in the
duplex tray.
Shorted
The Paper Jam C indicator lights even if
there is no paper.
Side Fence Jogger
HP [Duplex
machines only]
(S31)
140-7 Open
E525 is displayed.
Shorted
E524 is displayed.
End Fence Jogger
HP [Duplex
machines only]
(S32)
140-8 Open
E523 is displayed.
Shorted
E522 is displayed.
Original Length
[Option for N.
American models]
(S33)
118-7 Open
The CPU cannot detect the original size
properly. APS and ARE do not function
correctly.
Shorted
Rev. 7/95
FT5535/4527/4522 6-46 FSM
