2.2 DRIVE LAYOUT
1. Vertical Transport Roller Gears
2. Paper Feed Clutch 1
3. Paper Feed Clutch 2
4. Separation Roller Gears
5. Paper Feed Clutch 3
6. Main Motor
7. Relay Clutch
8. Timing Pulley
1
2
1
3
4
5
6
7
8
4
4
FSM 8-3 FT5535/4527/4522
