2. COMPONENT LAYOUT
2.1 MECHANICAL COMPONENT LAYOUT
1. Proof Tray
2. Proof Tray Exit Rollers
3. Vertical Transport Rollers
4. Turn Gate
5. Bin Transport Belt
6. Bin Transport Roller
7. Bin Exit Roller
8. Stapler
9. Grip Assembly
10. Bin Support Block
11. Bins
12. Support Bin
13. Jogger Bar
1
2
3
4
5
6
7
8
9
10
11
12
13
FSM 10-3 FT5535/4527/4522
