Mode No. Function Settings
2-802 Drum Charge
Roller
Temperature †
Displays the drum charge roller temperature [0
~ 60°C].
2-812 Drum Reverse
Rotation
Adjustment †
Adjusts the amount of the time for the drum
reverse rotation after each copy job.
0 ~ 32
Default = 16
(about 3 mm)
If paper dust remains on the drum, it may get
into the recycled toner. If this is happening,
increase the reverse rotation by increasing the
value of the setting.
2-901 Drum Charge
Roller Cleaning
Interval †
Selects the drum charge roller cleaning
interval.
Turn the copier main switch off and on after
changing the setting.
0: Every 1000
copies
1: Every 500
copies
2: Every 200
copies
3: Every 100
copies
The drum charge roller is cleaned briefly at the
end of each copy job. The drum charge roller
is also cleaned for 10 seconds after the
interval selected with this SP mode.
2-902 Not Used -
3-001 ID Sensor Initial
Setting
Performs the ID sensor initial setting. ID
sensor output for the bare area of the drum
(V
SG) is adjusted to 4.0 ± 0.2 V.
To start this SP mode, press the "Start" key.
3-002 ID Sensor Initial
Setting Display
†
Displays the initial setting value of the ID
sensor.
Normally 4.0 ± 0.2 V is displayed. If the ID
sensor cannot be adjusted to 4.0
± 0.2 V, the
ID sensor or the OPC drum should be cleaned.
3-103-001
to
3-103-002
ID Sensor
Output Display †
Displays the ID sensor outputs.
SP3-103-001: V
SP
SP3-103-002: VSG
Normally, V SP = 0.01 ~ 2.50 V, V SG = 4.0 ±
0.2 V (V SP /V SG ≈ 0.1)
3-105 Forced VL
Detection
After the "Start" key is pressed, the initial
VLP/VLG (= VREF) is determined.
For when to use this SP mode, see "Practical
SP Mode Use Table".
3-106 Initial VLP/VLG
Display †
Displays the initial V
LP/VLG value determined
by SP3-105.
3-107 Current
V
LP/VLG
Display †
Displays the current V
LP/VLG value [%].
This is the value currently being used for V L
correction.
3-111 Current
V
RP/VRG
Display †
Displays the current V
RP/VRG value [%]
This is the value currently being used for V R
correction.
Rev. 7/95
FT5535/4527/4522 4-24 FSM
