3. Main SP Tables-5
SP5-009 to 721 (Mode)
5009
[Add Display Language]
Adds language available in user choice. (Only the languages registered in the machine)
Refer to the displayed language list to set in the way showed below.
List Number Assigned Bit Switch
No.1 to 8 BIT1 to 8 (SP5009-201)
No.9 to 16BIT1 to 8 (SP5009-202)
No.17 to 24BIT1 to 8 (SP5009-203)
No.25 to 32BIT1 to 8 (SP5009-204)
Example: To add American(No.3 in the list) or Czech (No.15)
Turn Bit 3 of “SP5009-201” 0 to 1 for American.
Turn Bit 7 of “SP5009-202” 0 to 1 for Czech.
After setting, turn the main power switch off and on to make the setting valid.
201 1-8 *CTL [1 to 255 / 00000000 / 1/step]
202 9-16 *CTL [1 to 255 / 00000000 / 1/step]
203 17-24 *CTL [1 to 255 / 00000000 / 1/step]
204 25-32 *CTL [1 to 255 / 00000000 / 1/step]
5024
[mm/inch Display Selection]
Display units (mm or inch) for custom paper sizes.
001 0:mm 1:inch *CTL
[0 or 1 / 0 / 1/step]
0: mm (Europe/Asia)
1: inch (USA)
5037 [Status Lamp Mode]
189
