Ricoh MP C6502SP System Maintenance

20 and lager
ID Sensor
21 ID Sensor Vsg adjust error
Out of range from
Vsg=4.0±x.x[V/step]
22 ID Sensor LED Adjust error Ifsg>Max
23
ID Sensor Output error(Positive
reflect)
Vsg_reg<Min(Max)
24
ID Sensor output error(Diffusion
reflect)
Vsg_dif<Min(Max)
25
ID Sensor offset Voltage
error(Positive reflect)
Voffset_reg>Max
26
ID Sensor offset Voltage
error(Diffusion reflect)
Voffset_dif>Max
45 and lager
ID Pattern detect
45 ID Pattern extract error Can not detect ID Pattern
50 Vmin_Bk/K2 error(Max) K:Vmin_Bk / CMY:K2>Max
51 Vmin_Bk/K2 error(Min) K:Vmin_Bk / CMY:K2<Min
52 K5 error(Max) K5>Max
53 K5 error(Min) K5<Min
54
K5 calculated approximate
point error
K5 calculated approximate
point <Min
55 Develop gamma error(Max) Develop gamma >Max
56 Develop gamma error(Min) Develop gamma <Min
57
Start developing voltage:Vk
error(Max)
Start developing
voltage:Vk>Max
58
Start developing voltage:Vk
error(Min)
Start developing
voltage:Vk<Min
59 Not enough valid data
Adhesion amount data for
develop gamma calculation
point is under 2
SP3-XXX (Process)
7
