SYSTEM SPECIFICATIONS
RICOH Pro C5100s/C5110s
R3440
Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355, 1-800-63-RICOH
Ricoh
®
and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. All other trademarks are the property of their respective owners. ©2013 Ricoh Americas Corporation. All rights
reserved. The content of this document, and the appearance, features and specifications of Ricoh products and services are subject to change from time to time without notice. Products
are shown with optional features. While care has been taken to ensure the accuracy of this information, Ricoh makes no representation or warranties about the accuracy, completeness or
adequacy of the information contained herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services,
and the conditions and factors affecting performance. The only warranties for Ricoh products and services are as set forth in the express warranty statements accompanying them.
Specifications
Print/Copy Process 4 drum dry electrostatic transfer system with
internal transfer belt
Fusing Oil-less belt fusing method
System Memory 320GB (160GB x 2)
Document Feeder 220-Sheet ADF with single-pass color duplex
scanning at up to 220 ipm
Control Panel Full-color 9" WVGA touch panel
Copy Resolution 600 dpi
Print Resolution 1200 x 4800 dpi
Scan Resolution 600 dpi
Scan Speed (FC/B&W) Simplex: 120 ipm; Duplex: 220 ipm
Maximum Print Area Up to 12.7" x 18.9" (323 x 480mm)
(from platen)
Warm-Up Time Less than 299 sec.
Output Speed Pro C5100s: 65 ppm (FC/B&W)
Pro C5110s: 80 ppm (FC/B&W)
Paper Capacity Tray 1: 1,250 x 2; Trays 2 – 3: 550 x 2;
Bypass Tray: 250 sheets; Supports duplex;
Total Standard/Maximum: 3,850/8,250 sheets
Paper Size Tray 1: 8.5" x 11"; Trays 2 – 3: 5.5" x 8.5"
– 13" x 19.2"; Bypass: 5.5" x 8.5" – 13" x
19.2", Envelopes
Paper Weight Tray 1 – 3: 16 lb. Bond – 140 lb. Index (52 –
256 g/m
2
); Bypass Tray: 16 lb. Bond – 110 lb.
Cover (52 – 300 g/m
2
); Duplex: 16 lb. Bond
– 140 lb. Index (52 – 256 g/m
2
)
Maximum Monthly Volume 150K
Duty Cycle 300K
Power Requirements 208-240V/12A/60Hz (dedicated)
Maximum Power 2,400W or less
Consumption
Dimensions (WxDxH) 32.9" x 34.6" x 48.4" (835 x 880 x 1,230mm)
(including ADF)
Weight Less than 574 lbs. (261 kg)
Copier Features
Simplified Display, Auto Paper Selection, Auto Start, Auto Tray Switching,
Auto Image Density, Auto Color Calibration, Interrupt Copy, User Codes
(1,000), Job Programs (25), Color Erase/Convert/Overlay, Electronic Sort/
Stack, Image Rotation, Rotate Sorting, Bates Numbering, Multiple Security
Features (DOSS, Data Encryption (AES256bit/SHA2), Network User
Authentication, Unauthorized Copy Control, Mandatory Security Information
Print (Compulsory Security Stamp), SMTP over SSL
Accessories
RT4030 DLT Large Capacity Tray (LCT)
Paper Capacity 2,200 sheets
Paper Size Up to 13" x 19.2"
Paper Weight 16 lb. – 110 lb. Cover (52 – 300 g/m
2
)
Dimensions (WxDxH) 34.2" x 28.7" x 25.9" (869 x 730 x 658mm)
Weight 180 lbs. (82 kg)
RT4020 Large Capacity Tray (LCT)
Paper Capacity 4,400 sheets
Paper Size 8.5" x 11"
Paper Weight 16 lb. – 80 lb. Cover (52 – 216 g/m
2
)
Dimensions (WxDxH) 19.7" x 21.3" x 24.6" (500 x 540 x 625mm)
(with LG unit)
Weight 44 lbs. (20 kg)
CI4010 Cover Interposer
Paper Size 5.5" x 8.5" – 13" x 19.2"
Paper Weight 17 lb. Bond – 80 lb. Cover (64 – 216 g/m
2
)
Stack Capacity 200 sheets
Dimensions (WxDxH) 19.7" x 23.6" x 23.6" (500 x 600 x 600mm)
Weight 26 lbs. (12 kg)
CI4020 Two-Source Cover Interposer
Paper Size 5.5" x 8.5" – 13" x 19.2"
Paper Weight 17 lb. Bond – 80 lb. Cover (64 – 216 g/m
2
)
Stack Capacity 200 sheets x 2 trays
Dimensions (WxDxH) 21.2" x 28.7" x 50" (540 x 730 x 1270mm)
Weight 99 lbs. (45 kg)
SR4090 3,000-Sheet Finisher with 65-Sheet Stapler
Capacity (Proof Tray) 250 sheets (8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Capacity (Shift Tray) 8.5" x 11": 3,000 sheets
8.5" x 14" – 13" x 19.2": 1,500 sheets
Paper Size 5.5" x 8.5" – 13" x 19.2"
Paper Weight Proof Tray: 16 lb. Bond – 80 lb. Cover (52 –
220 g/m
2
); Shift Tray: 16 lb. Bond – 110 lb.
Cover (52 – 300 g/m
2
)
Staple 8.5" x 11" – 11" x 17": 65 pages;
13" x 19.2": paper cannot be stapled
Dimensions (WxDxH) 25.8" x 24.1" x 37.8" (657 x 613 x 960mm)
Weight 117 lbs. (53 kg)
SR4110 3,000-Sheet Finisher with 100-Sheet Stapler
Capacity (Proof Tray) 500 sheets (8.5" x 11" or smaller)
250 sheets (8.5" x 14" or larger)
Capacity (Shift Tray) 8.5" x 11": 3,000 sheets; 8.5" x 14" – 11" x
17": 1,500 sheets; 12" x 18" – 13" x 19.2":
1,000 sheets
Paper Size 5.5" x 8.5" – 13" x 19.2"
Paper Weight Proof Tray: 16 lb. Bond – 80 lb. Cover (52
– 216 g/m
2
); Shift Tray: 16 lb. Bond – 110 lb.
Cover (52 – 300 g/m
2
)
Staple 8.5" x 11": 100 pages
8.5" x 14" – 11" x 17": 50 pages
Dimensions (WxDxH) 31.7" x 28.7" x 38.5" (806 x 730 x 980mm)
Weight 165 lbs. (75 kg)
SR4100 2,000-Sheet Booklet Finisher
Capacity (Proof Tray) 250 sheets (8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Capacity (Shift Tray) 8.5" x 11": 2,000 sheets
8.5" x 14" – 13" x 19.2": 1,000 sheets
Paper Size 5.5" x 8.5" – 13" x 19.2"
Paper Weight Proof Tray: 16 lb. Bond – 80 lb. Cover (52 –
216 g/m
2
); Shift Tray: 16 lb. Bond – 110 lb.
Cover (52 – 300 g/m
2
)
Staple 8.5” x 11” – 11” x 17”: 65 pages;
13” x 19.2”: paper cannot be stapled
Saddle Stitch Staple 8.5" x 11" – 13" x 19.2": 20 pages
Folding Without Staple 1 – 5 sheets
Dimensions (WxDxH) 25.8" x 24.1" x 37.8" (657 x 613 x 960mm)
Saddle Stitch Weight 28 lb. Bond Max. (64 – 105 g/m
2
)
Weight 117 lbs. (53 kg)
FD5000 Multi-Folding Unit
Folding Type Single Sheet Mode: Z-Fold, Half-Fold/Print
inside, Half-Fold/Print outside, Letter Fold-in/
Print inside, Letter Fold-in/Print outside, Letter
Fold-out, Double Parallel/Print inside, Double
Parallel/Print outside, Gate-Fold/Print inside,
Gate-Fold/Print outside
Multiple Sheets Mode Same as Single Sheet mode; up to 3 sheets
Paper Size Single Sheet Mode: Z folding: 8.5" x 11" –
12" x 18"; Half folding: 8.5" x 11" – 13" x
19.2"; Letter folding: 8.5" x 11" – 12" x 18"
Multiple Sheets Mode
Double Parallel folding: 8.5" x 11" – 12" x
18"; Gate folding: 8.5" x 11" – 12" x 18"; Half
folding: 8.5" x 11" – 13" x 19.2"; Letter Fold-
out: 8.5" x 11" – 12" x 18"; Letter Fold-in: 8.5"
x 11" – 12" x 18"
Dimensions (WxDxH) 18.5" x 38.5" x 28.75" (470 x 980 x 730mm)
Weight 203 lbs. (92 kg)
Buffer Pass Unit
Paper Size Up to 13" x 19.2"
Paper Weight 16 lb. – 110 lb. Cover (52 – 300 g/m
2
)
Dimensions (WxDxH) 13" x 38.6" x 28.5" (330 x 980 x 725mm)
Weight 202 lbs. (92 kg)
Decurl Unit
Decurl Function Five steps pressure adjustment (from
operation panel)
Paper Size Up to 13" x 19.2"
Paper Weight 16 lb. – 110 lb. Cover (52 – 300 g/m
2
)
Dimensions (WxDxH) 6.7" x 38.9" x 28.7" (170 x 990 x 730mm)
Weight 66 lbs. (30 kg)
GBC StreamPunch
Paper Size Punched 8.5" x 11" LEF
Paper Weight 20 lb. Bond – 110 lb. Index (216 g/m
2
)
Die Sets CombBind
®
, Twin Loop Wire (2:1 or 3:1),
ColorCoil
®
, VeloBind
®
, Three-Ring, ProClick
®
BK5010e Production Booklet Maker
Paper Size 8.5" x 11" – 11" x 17"
Paper Weight 16 lb. Bond – 110 lb. Index (216 g/m
2
)
Additional Accessories
PU5000 Punch Unit; PU3060 Punch Unit; Output Jogger Unit Type M2;
11" x 17" Tray Unit Type M2; Tab Sheet Holder Type M2; File Format
Converter Type E; Copy Data Security Kit Type G; Copy Tray Type M2;
Cooling Fan Unit Type M2; TCRU Type 5100
Fiery E-22B Color Controller Specifications
Controller Type Embedded Type
Fiery Platform Fiery FS100
Maximum Continuous Pro C5100s: 65 ppm (FC/B&W)
Print Speed Pro C5110s: 80 ppm (FC/B&W)
CPU Intel Pentium G850 2.9GHz
Host Interface 10/100/1000Base-TX Ethernet
Memory 2GB
Internal HDD 500GB
Operating System Linux
Network Protocol TCP/IP (IPv4/IPv6), SMB
Printer Description Language
Adobe PostScript 3 (std.), PCL6/5c (std.)
Maximum Print Resolution 1200 x 4800 dpi
Maximum Scan Resolution Up to 600 dpi
Fonts PS3: 138 fonts/PCL: 80 AGFA fonts
Operation Panel Via touch panel display on the MFP
Utilities Standard: Command WorkStation 5, Fiery
Scan, Printer Delete Utility, Fiery Web Tools,
Fiery Bridge, Fiery VUE, Secure Print
Optional: Fiery Impose, Fiery Compose, Color
Profiler Suite ES-2000, Productivity Package
Color Management Tools ICC Profile, Color Chart, CMYK Color
Reference Pages, RGB Color Tests, Trapping
Support, ColorWise Pro Tools
Calibration Color Cal, ES-2000 (opt.)
Fiery E-42B Color Controller Specifications
Controller Type Server Type
Fiery Platform Fiery FS100 Pro
Maximum Continuous Pro C5100s: 65 ppm (FC/B&W)
Print Speed Pro C5110s: 80 ppm (FC/B&W)
CPU Intel i5-2400 3.1GHz
Host Interface 10/100/1000Base-TX Ethernet
Memory 2GB
Internal HDD 1TB
Operating System Windows 7 Professional
Network Protocol TCP/IP (IPv4/IPv6), SMB
Printer Description Language
Adobe PostScript 3 (std.), PCL6/5c (std.)
Print Resolution 1200 x 4800 dpi
Scan Resolution 600 dpi
Fonts PS3: 138 fonts/PCL: 80 AGFA fonts
Operation Panel Via touch panel display on the MFP
Utilities Standard: Command WorkStation 5, Fiery
Scan, Printer Delete Utility, Fiery Web Tools,
Fiery Bridge, Fiery VUE
Optional: Fiery Impose, Fiery Compose, Color
Profiler Suite ES-2000, Graphic Arts Package
Premium Edition Upgrade, FACI Furniture
Bundle, HDD Security
Color Management Tools ICC Profile, Color Chart, CMYK Color
Reference Pages, RGB Color Tests, Trapping
Support, ColorWise Pro Tools
Calibration Color Cal, ES-2000 (opt.)
Power Requirements 100-240V/3.0A/50-60Hz
Maximum Power 350W
Consumption
Dimensions (WxDxH) 8.3" x 19" x 19.2" (212 x 482 x 488mm)
Weight 43.1 lbs. (19.6 kg)
Supplies
Toner Yield (prints/bottle)
Black 30K
Cyan 30K
Magenta 30K
Yellow 30K
Waste Bottle 40K
For maximum performance and yield, we recommend using genuine Ricoh parts
and supplies.
