Curl Correction
Do some test prints and check for excessive curling.
Do test prints with paper feed from each paper tray.
Curl correction is done with settings in the SP mode. There
are six SP codes for curl correction, one for each paper
tray.
1st Tray of Main Machine: SP1906 001
2nd Tray of Main Machine: SP1906 002
Top Tray of LCIT: SP1906 003
Middle Tray of LCIT: SP1906 004
Bottom Tray of LCIT: SP1906 005
Bypass Tray (on top of LCIT): SP1906 006
Possible settings
1: Slight Face Curl
2: Excessive Face Curl
3: None. This is the normal default setting. No pressure is
applied by the soft roller.
4: Slight Back Curl
5: Excessive Back Curl
Face curl: the leading and trailing edges of the sheets curl up
Back curl: the leading and trailing edges of the sheets curl down
