Ricoh PRO C751 - Page 234

Taurus-C1 Training
234
Slide 234
Left Drawer: Pulling it Out
 Lower the lock lever [A].
 Pull the drawer out [B] until it stops.
 The left drawer contains the PTB, fusing unit, paper cooling unit, and the 1st half
of the duplex path.
