Taurus-C1 Training
243
Slide 243
Re-installing a PCDU (2)
Always check the left side of the PCDU before you push it back
into the machine.
This is the shield plate that conducts heat away from the
development unit.
If you see any toner on the plate, wipe it off with a clean dry cloth.
To prevent toner scatter or gear damage, never apply excessive
force on the PCDU when you push it into the machine.
No additional notes
