Taurus-C1 Training
274
Slide 274
Removal
There are two laser units.
The unit on the left is for yellow and magenta
(YM).
The unit on the right is for cyan and black (CK)
The removal procedures for each machine are
different.
The D074/D075 has an ARDF that must be
removed, and the scanner unit must be propped
up with a support rod for servicing.
The M044 has no ARDF or scanner unit, so
removal of the laser unit is much easier.
Never open the laser unit. It is replaced as a
complete unit.
For the D074/D075, the procedure is very long because a lot of units must be
removed.
