Ricoh Pro L5130 - Characters Are Faint (Case3)

When Print Quality Is Not Satisfactory
26
Characters Are Faint (Case3)
Characters are faint (a line is double) in the image on the left and right side (does not occur
at the center.)
left center right
[Cause/Technical reason]
If media skew occurs, the image written by print head 1 and print head 3 will not be
overlapped.
(Describing the following figure)
If media is skewing, media may be fed in the direction of rotation.
In that case, misalignment occurs in the vertical direction.
a b c d e f g
Print
Head
1
Print
Head
1
Print
Head
2
Print
Head
3
a b c d e f g
a b c d e f g
Printed By Head 1
Printed By Head 3
If media is skewing,
misalignment occurs.
Media
